- Camera
- Image Sensor 1/2.9″ Progressive Scan CMOS
- Max. Resolution 1920 × 1080
- Min. Illumination Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR
- Shutter Time 1 / 3 s to 1 / 100,000 s
- Day & Night IR cut filter
- Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
- Lens
- Lens Type Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°
4 mm, horizontal FOV 80°, vertical FOV 44°, diagonal FOV 94°
- Lens MountM 12
- Iris Type Fixed
- Aperture F 2.2
- DORI
- DORI
2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m
4 mm, D: 55 m, O: 22 m, R: 11 m, I: 5 m
- Illuminator
- Supplement Light Type IR,White Light
- Supplement Light Range
IR: up to 20 m
White Light: up to 15 m
- Smart Supplement Light Yes
- IR Wavelength 850 nm
- Video
- Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
- Video Compression
Main stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream: H.265 / H.264 / MJPEG
- Video Bit Rate 32 Kbps to 8 Mbps
- H.264 Type Baseline Profile ,Main Profile ,High Profile
- H.265 Type Main Profile
- Bit Rate Control CBR,VBR
- Audio
- Audio Type Mono sound
- Environment Noise Filtering Yes
- Audio Sampling Rate8 kHz / 16 kHz
- Audio Compression G.711u law/AAC-LC
- Audio Bit Rate 64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
- Network
- Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, security audit log, host authentication (MAC address)
- Simultaneous Live View Up to 6 channels
- API Open Network Video Interface (Profile S, Profile T),ISAPI,SDK
- Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv4, IPv6, UDP, QoS, SMTP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Client iVMS-4200 ,Hik-Connect
- Web Browser
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image
- Wide Dynamic Range (WDR)Digital WDR
- SNR ≥ 52 dB
- Privacy Mask 1 programmable polygon privacy mask
- Day / Night Switch Day ,Night, Auto ,Schedule
- Image Enhancement BLC, HLC ,3 D DNR
- Image Settings Saturation, brightness ,contrast ,sharpness ,gain ,white balance, adjustable by client software or web browser
- Interface
- Ethernet Interface1 RJ45 10 M / 100 M self-adaptive Ethernet port
- On-Board Storage
NA
- Built-in Microphone Yes ,1 built-in microphone
- Reset Key
NA
- Event
- Basic Event Motion detection (support alarm triggering by specified target type (human)), exception
- Linkage Notify surveillance center, send email, trigger capture
- General
- Power
12 VDC ± 25%, 0.41 A, max. 5 W,Ø5.5 mm coaxial power plug ,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 6.5 W
- Material Plastic
- Dimension Ø109.9 mm × 103.6 mm (Ø4.3″ × 4.1″)
- Package Dimension 134 mm × 134 mm × 108 mm (5.3″ × 5.3″ × 4.3″)
- Weight Approx. 300 g (0.7 lb.)
- With Package Weight Approx. 460 g (1.0 lb.)
- Storage Conditions-30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions-30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
- Language English, Ukrainian
- General Function Heartbeat ,anti -banding, mirror, password protection ,password reset via email
- Approval
- EMC
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 6 1000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014
- Safety
CB: IEC 623 68 -1: 2014+ A11,
CE-LVD: EN 6236 8-1: 2014 / A11: 2017
- Environment
CE-RoHS: 2011 / 65 / EU,
WEEE: 2012 / 19 / EU,
Reach: Regulation (EC) No 1907 / 2006
- Protection IP67: IEC 60529-2013
