Ubiquiti airFiber 5G34-S45

5 GHz, 34 dBi antenna ideal for long range Point-to-Point (PtP) links.

  • 2 x 2 dual-polarity performance
  • Robust mechanical design for outdoor application use
  • Secure pole-mounting
  • Compatible with airFiber 5XHD
Compare
Add to wishlist
SKU: AF-5G34-S45 Categories: , ,
Description

AF-5G34-S45

Dimensions 1050 x 1050 x 421 mm (41.34 x 41.34 x 16.57″)

Weight With Mount: 13.5 kg (29.76 lb)

Frequency 5.1 – 5.8 GHz

Gain 34 dBi Max.

VSWR1.4:1

Wind Survivability 200 km/h (125 mph)

Wind Loading 1,779 N @ 200 km/h (400 lb @ 125 mph)

Polarization Dual Linear

F/B Ratio 42 dB

ETSI Specification EN 302 326 DN2

Mounting Universal Pole Mount, airFiber Radio Bracket, and Weatherproof RF Jumpers Included

Additional information
Weight1 kg
Dimensions10 × 10 × 10 cm
