| Standard&Protocol | IEEE802.3, IEEE802.3u, IEEE802.3ab |
| Interfaces | 1× Gigabit WAN Port 3× Gigabit LAN Ports |
| Antenna | 5*6dbi external antennas |
| Button | 1*WPS/Mesh button 1*Reset button |
| Power | Input：AC 100-240V~50/60Hz Output:DC 12V⎓1A |
| LED Indicator | 1* LED |
| Dimension | (L*W*H)267*166*222 mm |
| Wireless Standard | IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
| Data Rate | 5 GHz: 2402 Mbps (802.11ax, HE160) 2.4 GHz: 574 Mbps (802.11ax) |
| Frequency | CE: 2.4G: 2412-2472MHz(CH1-CH13) 5G: 5150-5350MHz(CH36-CH64) FCC: 2.4G: 2412-2462MHz(CH1-CH11) 5G: 5150-5350MHz(CH36-CH64) 5725-5850MHz(CH149-CH165) |
| Transmission Power | CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) FCC: <30 dBm (2.4 GHz) <30 dBm (5 GHz) |
| Basic Features | SSID broadcasting and hiding MU-MIMO Beamforming signal directional transmission technology 160MHz OFDMA 1024-QAM |
| Wireless Security | WPA2-PSK WPA3-SAE/WPA2-PSK Wireless Security: Enable/Disable WPS(WiFi Protected Set-up) fast encryption |
| Internet Connection Type | PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) Unify,Maxis,Maxis-special,Celcom,Digi |
| Network Protocol | IPv4&IPv6 |
| Operating Mode | Router Mode AP Mode Universal Repeater Mode（Client+AP,WISP） |
| Parental Control | Client Filter URL Filter Time Limit |
| DHCP | DHCP Server DHCP Client List DHCP Static IP Address Reservation and Allocation |
| Virtual Server | Port Forwarding, DMZ Host, UPnP |
| Firewall | ICMP Flood Attack Defense TCP Flood Attack Defense UDP Flood Attack Defense Block Ping From WAN |
| DDNS | DynDNS, no-ip, oray, 88ip |
| VPN | IPSec Transparent Transmission PPTP Transparent Transmission L2TP Transparent Transmission PPTP VPN Server PPTP VPN Client L2TP VPN Client |
| Special Features | Wi-Fi+(Mesh System) Smart diagnosis IPTV IPv6 Smart LED on/off |
| Other Function | Support App and web management Bandwidth Control Guest Network MAC Address Clone Supports black list and white list Unify 2.4 GHz & 5 GHz Static Routing Remote Web Management Backup & Restore configurations Firmware upgrade online |
| Temperature | Operating Temperature : 0℃~40℃ Storage Temperature : -40C ~70℃ |
| Humidity | Operating Humidity : 10 %~90% RH non-condensing Storage Humidity : 5 %~ 90%RH non-condensing |
| Certification | CE, FCC,RoHS |
| Package Contents | Wi-Fi Router *1 RJ45 Ethernet Cable*1 Power Adapter*1 Quick Installation Guide*1 |
