Tenda S105
5-port Ethernet Switch
- 5*10/100 Mbps auto-negotiation RJ45 ports obtains the fastest possible connection
- Compliant with IEEE802.3，IEEE802.3u，IEEE802.3X standard
- 5* LED indicators display the connection status
- Supports 10/100M full duplex and half duplex
- Store-and-forward mode
- Supports MAC address auto learning and auto aging
- Supports to connect with IP-camera
- Plug-and-play without configuration
- Supports wall-mounting and desktop installation Energy saving technologies help you save power and money
₨1,800.00
17
People watching this product now!
Description
Hardware
Network standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x
LED Indicator 1* Power, 5* Link/Act
Interfaces 5*10/100 Base-TX Ethernet ports (Auto MDI/MDIX)
Transmission media
Recommended: CAT5/5e UTP or better
Fan quantity N/A
Dimension 82.0mmx52.0mmx22.3mm
Material Plastic
Level of protection
ESD:
Air discharge: ±8kV
Contact discharge: ±6kV
Air discharge: ±8kV
Contact discharge: ±6kV
Forwarding mode
Store-and-forward
Switch capacity 1.0Gbps
Packet forwarding rate 0.74Mpps
Buffer 448K
MAC address table 1K
Jombo frame N/A
Power
Input: 100-240V AC 50/60Hz
Output: 5.0V 0.6A ( External Power Adapter )
Output: 5.0V 0.6A ( External Power Adapter )
Power consumption Max:<1.6W
Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting: non-support
Wall mounting: support
Rack mounting: non-support
Environment
Operating temperature: 0°C – 45℃
Storage temperature: -40°C – 70°C
Operating humidity: (10% – 90%) RH, non-condensing
Storage humidity: (5% – 90%) RH, non-condensing
Storage temperature: -40°C – 70°C
Operating humidity: (10% – 90%) RH, non-condensing
Storage humidity: (5% – 90%) RH, non-condensing
Certification CE, FCC, RoHS
Software
Protocols
CDMA/CD MAC address learning
Auto-Learning and Auto-Aging
Functions plug-and-play
