Standard&Protocol : IEEE 802.3/u/x/ab
Interface : 5* 10/100/1000Mbps auto-negotiation RJ45 ports, auto MDI/MDIX
Transmission Media : 10BASE-T: Cat.3 or Above
:100BASE-TX/1000BASE-T: Cat.5, Cat.5e or Above
:100BASE-TX/1000BASE-T: Cat.5, Cat.5e or Above
Forwarding Rate : 10Mbps: 14880pps
:100Mbps: 148800pps
:1000Mbps: 1488000pps
:100Mbps: 148800pps
:1000Mbps: 1488000pps
LED : 5*10/100/1000Mbps Link/Act LEDs
: 1*power LED
: 1*power LED
Features : Store-and-forward mechanism
:Auto-learning and auto-aging MAC address
:Switching capacity of 10Gbps
:Auto-learning and auto-aging MAC address
:Switching capacity of 10Gbps
Power Input : 100-240V~50/60Hz
Power Output : 5V/0.6A
Consumption : Standby: 0.5W Maximum:2.5W(220V/50Hz)
Dimension : 96*66*23mm
Operation Temperature : 0℃~45℃
Operating Humidity : 10%~90% non-condensing
Storage Temperature : -40℃~70℃
Storage Humidity : 5%~90% non-condensing
