Name: Hikvision DS-2CD1363G2-LIUF/SL
SKU: DS-2CD1363G2-LIUF/SL
Availability: InStock

Hikvision DS-2CD1363G2-LIUF/SL

Camera
Image Sensor 1 / 2.4″ Progressive Scan CMOS
Max. Resolution 3200 × 1800
Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON) ,B/W: 0 Lux with IR
Shutter Time 1 / 3 s to 1 / 100,000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
Lens Type Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV 2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°
Lens MountM 12
Iris Type Fixed
Aperture F1.6
DORI
DORI 2.8 mm, D: 76 m, O: 30 m, R: 15 m, I: 7 m
Illuminator
Supplement Light Type IR,White Light
Supplement Light Range Up to 30 m
Smart Supplement Light Yes
IR Wavelength 850 nm
Video
Main Stream
50 Hz:
20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
Video Compression
Main stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream: H.265 / H.264 / MJPEG
Video Bit Rate 32 Kbps to 1 6 Mbps
H.264 Type Base line Profile ,Main Profile ,High Profile
H.265 Type Main Profile
Bit Rate Control CBR,VBR
Region of Interest (ROI) 1 fixed region for main stream
Scalable Video Coding (SVC)H.264 and H.265 encoding

Audio
Audio Type Mono sound
Audio Sampling Rate 8 kHz / 16 kHz
Environment Noise Filtering Yes
Audio Compression G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
Audio Bit Rate 64 Kbps (G.711 l aw / G.711alaw) / 16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

Network
Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Simultaneous Live View Up to 6 channels
API Open Network Video Interface (Profile S, Profile T, Profile G),ISAPI,SDK
Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
User/Host
Up to 32 users
3 user levels: administrator, operator, and user
Client iVMS-4200,Hik-Connect
Web Browser
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Fire fox 52.0+, Edge 89+

Wide Dynamic Range (WDR)120 dB
SNR ≥ 52 dB
Day / Night Switch Day ,Night ,Auto ,Schedule
Image Enhancement BLC,HLC,3D DNR
Image Settings Rotate mode ,saturation ,brightness ,contrast ,sharpness ,gain ,white balance ,adjustable by client software or web browser
Privacy Mask 4 programmable polygon privacy masks

Interface
Ethernet Interface1 RJ45 10 M / 100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSD / micro SDHC / micro SDXC card, up to 512 GB
Built-in Microphone Yes,1 built-in microphone
Built-in Speaker Max. power consumption: 1.5 W, max. sound pressure level: 10 cm: 95 dB.
Reset Key Yes

Event
Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm ,exception
Linkage Upload to FTP / NAS / memory card, notify surveillance center ,send email, trigger recording, trigger capture, audible warning, flashing light

General
Power
12 VDC ± 25%, 0.66 A, max. 8 W,Ø5.5 mm coaxial power plug ,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 9.5 W
Material Metal & Plastic
Dimension Ø 110 mm × 102.7 mm (Ø4.33″ × 4.04″)
Package Dimension150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
Weight Approx. 340 g (0.7 lb.)
With Package Weight Approx. 560 g (1.2 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language English, Ukrainian
General Function Heartbeat ,anti-banding ,mirror, password protection ,password reset via email
Flashing Light Yes
