Tenda TX2L Pro

IEEE802.3, IEEE802.3u, IEEE802.3ab

1*10/100/1000Mbps WAN port
3*10/100/1000Mbps LAN ports

5*external antennas

1*WPS/Reset button

Input: AC 100-240V~50/60Hz
Output: DC 12V1A

1* LED

244*56*200mm(L*W*H)

IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz

5GHz:1201Mbps
2.4GHz:300Mbps

CE:
2.4G: 2412-2472MHz(CH1-CH13)
5G: 5180-5240MHz(CH36-CH64)
FCC:
2.4G: 2412-2462MHz(CH1-CH11)
5G: 5150-5250MHz(CH36-CH64)
5725-5850MHz(CH149-CH165)

CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
FCC:
<30 dBm (2.4 GHz)
<30 dBm (5 GHz)

OFDMA+MU-MIMO
Beamforming Signal Directional Transmission Technology

WPA2-PSK,WPA3-SAE,WPA3-SAE/WPA2-PSK
Wireless Encryption Disable and Enable
WPS Fast Connection

PPPOE, Dynamic IP, Static IP

IPv4&IPv6

Wireless Relay Mode (Client+AP)

Client Filter
Remote Web Management

DHCP Server
DHCP Client List
DHCP Static IP Address Reservation and Assignment

Port Forwarding, DMZ Host, UPnP

ICMP Flood Attack Defense
TCP Flood Attack Defense
UDP Flood Attack Defense
Ignore Ping Packet From WAN Port

Support DynDNS, No-ip

IPSec Transparent Transmission
PPTP Transparent Transmission
L2TP Transparent Transmission
PPTP VPN Server
PPTP VPN Client
L2TP VPN Client

Wi-Fi+(Mesh System)
IPTV
IPv6
Smart LED on/off

Smart Power Saving
Bandwidth Control
Guest Network
System Log
MAC Clone
Broadband Account Migration
Tenda App（Parental Control）
Backup & Restore Configurations
Support Automatic Access Detection
Upgrade Online

Operating Temperature : 0℃~40℃
Storage Temperature : -40C ~70℃

Operating Humidity : 10 %~90% RH non-condensing
Storage Humidity : 5 %~ 90%RH non-condensing

CE, FCC,RoHS

Dual Band Gigabit Wi-Fi 6 Router*1
Ethernet Cable*1
Power Adapter*1
Installation Guide*1
