Dual Band Gigabit Wi-Fi 6 Router

Speedy Wi-Fi 6
5 High Gain Antennas
Vertical Design
Whole Gigabit Ports
Parental Control
OFDMA+MU-MIMO

SKU: TendaTX2LPro Categories: Tenda, Wifi Routers

Hardware
Standard&Protocol
IEEE802.3, IEEE802.3u, IEEE802.3ab
Interfaces
1*10/100/1000Mbps WAN port
3*10/100/1000Mbps LAN ports
Antenna
5*external antennas
Button
1*WPS/Reset button
Power
Input: AC 100-240V~50/60Hz
Output: DC 12V1A
LED Indicator
1* LED
Dimension
244*56*200mm(L*W*H)
Wireless
Wireless Standard
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
Data Rate
5GHz:1201Mbps
2.4GHz:300Mbps
Frequency
CE:
2.4G: 2412-2472MHz(CH1-CH13)
5G: 5180-5240MHz(CH36-CH64)
FCC:
2.4G: 2412-2462MHz(CH1-CH11)
5G: 5150-5250MHz(CH36-CH64)
5725-5850MHz(CH149-CH165)
Transmission Power
CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
FCC:
<30 dBm (2.4 GHz)
<30 dBm (5 GHz)
Basic Features
OFDMA+MU-MIMO
Beamforming Signal Directional Transmission Technology
Wireless Security
WPA2-PSK,WPA3-SAE,WPA3-SAE/WPA2-PSK
Wireless Encryption Disable and Enable
WPS Fast Connection
Software
Internet Connection Type
PPPOE, Dynamic IP, Static IP
Network Protocol
IPv4&IPv6
Operating Mode
Wireless Relay Mode (Client+AP)
Parental Control
Client Filter
Remote Web Management
DHCP
DHCP Server
DHCP Client List
DHCP Static IP Address Reservation and Assignment
Virtual Server
Port Forwarding, DMZ Host, UPnP
Firewall
ICMP Flood Attack Defense
TCP Flood Attack Defense
UDP Flood Attack Defense
Ignore Ping Packet From WAN Port
DDNS
Support DynDNS, No-ip
VPN
IPSec Transparent Transmission
PPTP Transparent Transmission
L2TP Transparent Transmission
PPTP VPN Server
PPTP VPN Client
L2TP VPN Client
Special Features
Wi-Fi+(Mesh System)
IPTV
IPv6
Smart LED on/off
Other Function
Smart Power Saving
Bandwidth Control
Guest Network
System Log
MAC Clone
Broadband Account Migration
Tenda App（Parental Control）
Backup & Restore Configurations
Support Automatic Access Detection
Upgrade Online
Others
Temperature
Operating Temperature : 0℃~40℃
Storage Temperature : -40C ~70℃
Humidity
Operating Humidity : 10 %~90% RH non-condensing
Storage Humidity : 5 %~ 90%RH non-condensing
Certification
CE, FCC,RoHS
Package Contents
Dual Band Gigabit Wi-Fi 6 Router*1
Ethernet Cable*1
Power Adapter*1
Installation Guide*1
