| Standard&Protocol | IEEE 802.3, IEEE 802.3u,IEEE 802.3ab |
| Interfaces | 1*10/100/1000Mbps WAN port 3*10/100/1000Mbps LAN ports |
| Antenna | 5*6 dBi external antennas |
| Button | 1* WPS，1*Reset button |
| Power | Input：AC 100-240V~50/60Hz 0.6A Output：DC 12V⎓2A |
| LED Indicator | 1*SYS |
| Dimension | (L*W*H) 261*168*60mm |
| Wireless Standard | IEEE 802.11ax 6GHz IEEE 802.11ac/a/n/ax 5GHz IEEE 802.11b/g/n/ax 2.4GHz |
| Data Rate | 6GHz:Up to 2402 Mbps 5GHz:Up to 2402 Mbps 2.4GHz: Up to 861 Mbps |
| Frequency | CE: 2.4G: 2412-2472 MHz (CH1-CH13) 5G: 5150-5350 MHz (CH36-CH64) 6G: 5945-6425 MHz (CH1-CH93) FCC: 2.4G: 2412-2462 MHz (CH1-CH11) 5G: 5150-5350 MHz (CH36-CH64) 5725-5850 MHz (CH149-CH165) 6G: 5925-7125 MHz (CH1-CH233) |
| Transmission Power | CE: <20 dBm(2.4G) <23 dBm(5G) <23 dBm(6G) |
| Basic Features | SSID Broadcast: Enable/Disable Transmission Power: high, medium, low 1024 QAM High Data Rate 160 MHz Bandwidth Beamforming MU-MIMO OFDMA TWT BSS Color |
| Wireless Security | 2.4G/5G：WPA2-PSK WPA3-SAE/WPA2-PSK 6G：WPA3-SAE Wireless Security: Enable/Disable WPS(WiFi Protected Set-up) Fast Encryption |
| Internet Connection Type | PPPoE, Dynamic IP, Static IP PPPoE (Russia), PPTP (Russia), L2TP(Russia) Unify,Maxis,Maxis-special,Celcom,Digi |
| Operating Mode | AP Mode Wireless Router Mode Universal Repeater Mode（Client+AP,WISP） |
| DHCP | DHCP Server DHCP Client List DHCP Reservation |
| Virtual Server | Port Forwarding DMZ Host UPnP |
| Security | Client Filter Parental Control(support black list and white list) Remote Web Management |
| Firewall | Forbid UDP Flood Attack Forbid TCP Flood Attack Forbid ICMP Flood Attack Forbid WAN Ping from Internet |
| DDNS | NO-IP, Oray.com |
| VPN | PPTP Client PPTP Server L2TP Client PPTP Pass Through L2TP Pass Through IPSec Pass Through |
| Special Features | Alexa WiFi+(Mesh System) TR069 VLAN ID Smart diagnosis |
| Other Function | IPv6 Features Supported IPTV Smart Traffic Prioritisation Smart WiFi Schedule Smart Power Saving Smart LED on/off PPPoE Username/Password Clone Tenda App Bandwidth Control Guest Network System Log MAC Clone Backup & Restore Configurations Support Automatic Access Detection Firmware Upgrade Online Firmware Upgradeable via Browser |
| Temperature | Operating Temperature : 0℃~40℃ Storage Temperature : -40C ~70℃ |
| Humidity | Operating Humidity : 10 %~90% RH non-condensing Storage Humidity : 5 %~ 90%RH non-condensing |
| Default Settings | tenda wifi.com or http://192.168.0.1 |
| Certification | CE, RoHS, FCC |
| EIRP Power (Max) | 2.400-2.4835 GHz:19.83dBm (EIRP) 5.150-5.250 GHz:22.98dBm (EIRP) |
| Package Contents | Wireles Router*1 Power Adapter *1 Install Guide*1 Ethernet Cable*1 |
