Hardware
Standard & Protocol
IEEE 802.3, IEEE802.3u
Interfaces
10/100 Mbps WAN port*1
10/100 Mbps LAN port*3
10/100 Mbps LAN port*3
Antenna 5dBi External antenna*4
Button WPS/Reset button*1, WiFi on/off button*1
Power
AC input: 100-240V-50/60Hz, 0.2A
DC output: 9V 1A
DC output: 9V 1A
Dimension 171mm*171mm*210mm(L*W*H)
LED Indicator SYS*1, WiFi*1, WAN*1, LAN*3
Wireless
Wireless Standard
IEEE 802.11ac/a/n @5GHz
IEEE 802.11b/g/n @2.4GHz
IEEE 802.11b/g/n @2.4GHz
Data Rate
5GHz: 867Mbps
2.4GHz: 300Mbps
2.4GHz: 300Mbps
Frequency Concurrent dual band 2.4 GHz & 5 GHz
Transmission Power
CE:
<20dBm(2.4G)
<23dBm(5G)
FCC:
<30dBm
<20dBm(2.4G)
<23dBm(5G)
FCC:
<30dBm
Basic Features
SSID Broadcast: Enable/Disable
Beamforming
MU-MIMO
Beamforming
MU-MIMO
Wireless Security
WPA-PSK/WPA2-PSK, WPA/WPA2
Wireless Security: Enable/Disable
WPS(WiFi Protected Set-up) fast encryption
Wireless Security: Enable/Disable
WPS(WiFi Protected Set-up) fast encryption
Software
Internet Connection Type
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Operating Mode
Wireless Router Mode
Universal Repeater Mode
WISP Mode
AP Mode
Universal Repeater Mode
WISP Mode
AP Mode
DHCP Server
DHCP Server
DHCP Client List
DHCP Reservation
DHCP Client List
DHCP Reservation
Virtual Server
Port Forwarding
DMZ Host
UPnP
DMZ Host
UPnP
Security
Client Filter (support blacklist and whitelist)
Parental Control
Remote Management
Parental Control
Remote Management
Firewall
Forbid UDP flood attack
Forbid TCP flood attack
Forbid flood attack
Forbid WAN PING from internet
Forbid TCP flood attack
Forbid flood attack
Forbid WAN PING from internet
DDNS
Support DDNS, No-ip, 3322.org, Oray.com, 88ip
VPN
PPTP
L2TP
PPTP client
L2TP client
L2TP
PPTP client
L2TP client
Special Features
PPPoE Username/Password Clone
Smart WiFi Schedule
Smart Sleeping Mode
Smart LED on/off
Tenda WiFi App
Smart WiFi Schedule
Smart Sleeping Mode
Smart LED on/off
Tenda WiFi App
Others
IPv6 Features Supported
Bandwidth Control
Guest Network
IPTV
MAC Address Clone
System Log
Backup & Restore configurations
Online firmware upgrade
Local firmware upgrade
Bandwidth Control
Guest Network
IPTV
MAC Address Clone
System Log
Backup & Restore configurations
Online firmware upgrade
Local firmware upgrade
Others
Temperature
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃.
Storage Temperature: -40℃ ~ 70℃.
Humidity
Operating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.
Storage Humidity: 5% ~ 90%RH non-condensing.
Default Settings Default Access: tendawifi.com or http://192.168.0.1
Certification
CE/FCC/RoHS
EIRP Power (Max)
2.400 – 2.4835 GHz: 19.85 dBm (EIRP)
5.150 – 5.250 GHz: 22.96dBm (EIRP)
5.150 – 5.250 GHz: 22.96dBm (EIRP)
Package Contents
AC1200 Smart Dual-Band WiFi Router
Power Adapter
Quick Installation Guide
Ethernet Cable
Power Adapter
Quick Installation Guide
Ethernet Cable
