- System
- Operation System Linux
- Display
- Dimensions 4.3-inch
- Resolution 480 × 272
- Type LCD
- Operation Method Capacitive touch screen
- Video
- Pixel 2 MP
- Lens× 2
- Video Standard PAL (Default) and NTSC
- Network
- Wired Network 10 M/100 M self-adaptive
- Wi-Fi Support
- Interface
- Network Interface 1
- RS-485 1
- Wiegand 1
- Lock Output 1
- Exit Button 1
- Door Contact Input 1
- IO Input–
- IO Output–
- TAMPER 1
- USB1
- Capacity
- Card Capacity 3,000
- Face Capacity 1,500
- Fingerprint Capacity 3,000
- Event Capacity 150,000
- Authentication
- Card Type M1 card
- Card Reading Frequency 13.56 MHz
- Face Recognition Duration＜ 0.2 s
- Face Recognition Accuracy Rate＞99%
- Face Recognition Distance 0.3 to 1.5 m
- Fingerprint Recognition Duration＜1 s
- General
- Power Supply 12 VDC/1 A (power adapter included)
- Working Temperature -10 °C to 40 °C (14 °F to 104 °F)
- Working Humidity0 to 90% (No condensing)
- Dimensions 118.4 mm × 118.4 mm × 21.8 mm (4.66″ × 4.66″ × 0.86″)
- Application Environment Indoor
- Installation Wall Mounting; Base Mounting
- Language English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean; Japanese
- Weight
Gross weight: 0.71 kg (1.57 lbs)
Net weight: 0.23 kg (0.51 lbs)
- Function
- Face Anti-Spoofing Support
- Audio Prompt Support
- Time Synchronization Support
