- Display
- Screen Size 55 inch
- Active Display Area 1209.63 (H) mm × 680.34 (V) mm
- Backlight Direct-lit LED backlight
- Pixel Pitch 0.63 mm
- Physical Seam 0.88 mm
- Bezel Width 0.44 mm (top/left), 0.44 mm (bottom/right)
- Resolution 1920 × 1080@60 Hz (downward compatible)
- Brightness 500 cd/m²
- Viewing Angle Horizontal 178°, vertical 178°
- Color Depth 10 bit, 1.07 B
- Contrast Ratio 1100:1
- Response Time 8 ms
- Color Gamut 72% NTSC
- Surface Treatment Haze 28%, 2H
- Interface
- Video & Audio Input VGA × 1, HDMI × 1, DVI × 1, DP × 1, USB × 1
- Video & Audio Output HDMI × 1
- Control Interface RS232 IN × 1, RS232 OUT × 1
- Power
- Power Supply 100-240 VAC, 50/60 Hz
- Power Consumption ≤ 192 W
- Standby Consumption ≤ 0.5 W
- Working Environment
- Working Temperature 0°C to 40°C (32°F to 104°F)
- Working Humidity 10% to 90% RH (non-condensing)
- Storage Temperature -20°C to 60°C (-4°F to 140°F)
- Storage Humidity 10% to 90% RH (non-condensing)
- General
- Casing Material SECC
- VESA 600 (H) mm × 400 (V) mm
- Product Dimension (W × H × D)1210.81 mm × 681.76 mm × 68.9 mm (47.67” × 26.84” × 2.71”)
- Package Dimension (W × H × D)
Carton with two displays: 1404 mm × 910 mm × 464 mm (55.3” × 35.8” × 18.3”)
Carton with a single display: 1404 mm × 910 mm × 231 mm (55.3” × 35.8” × 9.1”)
- Net Weight 20.8 ± 0.5 kg (45.9 ± 1.1 lb) for single display
- Gross Weight 39.2 ± 0.5 kg (86.4 ± 1.1 lb) for carton with a single display
- Packing List Carton with a single display : LCD display × 1, power cable × 1, network cable × 1, 2-meter HDMI cable × 1, screw × 4, remote control × 1, IR receiver × 1, RS-232 converter × 1, quick start guide (multilingual) × 1, quick start guide (English) × 1
