- Camera
- Image Sensor 1/1.2＂ progressive scan CMOS
- Min. Illumination Color: 0.0005 Lux @ (F1.6, AGC ON), B/W: 0.0001 Lux @ (F1.6, AGC ON), 0 Lux with IR
- Shutter Speed 1/1 s to 1/30,000 s
- Slow Shutter Yes
- Day & Night IR cut filter
- Zoom 48x optical, 16x digital
- Max. Resolution 3840 × 2160
- Lens
- Focus Auto, semi-auto, manual, rapid focus
- Focal Length 6.0 mm to 288 mm, 48× Optical
- Zoom Speed approx. 7.8 s (optical, wide-tele)
- FOV
Horizontal field of view: 61.0° to 1.7° (wide-tele),
Vertical field of view: 35.9° to 1.0° (wide-tele),
Diagonal field of view: 68.5° to 1.9° (wide-tele)
- Aperture Max. F1.6
- Illuminator
- Supplement Light Type Laser
- Supplement Light Range Laser Distance: up to 500 m
- Smart Supplement Light Yes
- PTZ
- Movement Range (Pan) 360°，Smart Pan-Tilt Correction
- Movement Range (Tilt) -20° to 90° (auto flip)，Smart Pan-Tilt Correction
- Pan Speedpan speed: configurable from 0.1° to 210°/s; preset speed: 280°/s
- Tilt Speedtilt speed: configurable from 0.1° to 150°/s, preset speed 250°/s
- Proportional Pan Yes
- Presets 300
- Patrol Scan 8 patrols, up to 32 presets for each patrol
- Pattern Scan 4 pattern scans, record time over 10 minutes for each scan
- Power-off Memory Yes
- Park Action Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
- 3D Positioning Yes
- PTZ Status Display Yes
- Preset Freezing Yes
- Scheduled Task Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
- Video
- Target Cropping No
- Main Stream
50 Hz: 50 fps (3840 × 2160, 2560 × 1440), 100 fps (1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz: 60 fps (3840 × 2160, 2560 × 1440), 120 fps(1920 × 1080, 1280 × 960, 1280 × 720)
*High frame rate is supported under monitoring mode only.
- Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
- Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG
- Video Bit Rate 32 Kbps to 16384 Kbps
- H.264 Type Baseline Profile/Main Profile/High Profile
- H.265 Type Main Profile
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)8 fixed regions for each stream
- Audio
- Audio Compression G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM，AAC_LC
- Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)16 Kbps to 64 Kbps(AAC_LC)
- Audio Sampling Rate MP2L2: 16kHz, 32kHz, 48kHzAAC-LC: 16kHz, 32kHz, 48kHzPCM: 8kHz, 16kHz, 32kHz, 48kHzMP3: 8kHz, 16KHz, 32KHz, 48KHz
- Environment Noise Filtering Yes
- Network
- Smooth Streaming Yes
- Security Password protection,complicated password,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),watermark,IP address filter,basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS,control timeout settings,security audit log,TLS 1.3,host authentication (MAC address),TPM 2.0 (FIPS 140-2 level 2)
- Network Storage NAS (NFS, SMB/ CIFS), ANR
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour，WebSocket，WebSockets
- APIISUP, ISAPI, Hikvision SDK, Open Network Video Interface (Profile S, Profile G, Profile T, Profile M)，OTAP
- Simultaneous Live View Up to 20 channels
- User/HostUp to 32 users 3 user levels: administrator, operator, and user
- Client HikCentral, iVMS-4200, Hik-Connect
- Web Browser IE11, Chrome 57.0+, Firefox 52.0+, Safari 11+
- Image
- Day/Night SwitchDay, night, auto, scheduled-switch
- Image Enhancement BLC, HLC, 3D DNR
- Wide Dynamic Range (WDR)140 dB
- Defog Optical defog
- Image Stabilization OIS
- Regional Exposure Yes
- Regional Focus Yes
- Image Settings Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
- Image Parameters Switch Yes
- Privacy Mask Up to 24 masks, mosaic mask, mask color configurable, rectangle region
- SNR ≥ 52 dB
- Supplement Detection
- Satellite Positioning No
- Gyroscope Yes
- Compass No
- Interface
- Video Output 1.0 V[p-p]/75 Ω, PAL, NTSC, BNC connector
- ResetYes
- Ethernet Interface 1 RJ45 10M/100M self-adaptive Ethernet port
- On-board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC cards, up to 1 TB
- Alarm 7 inputs, 2 outputs
- Audio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
- RS-485 Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive
- Event
- Basic Event Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error),alarm input and output,vandal-proof alam,audio exception detection,unattended baggage detection, object removal detection
- Linkage Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,and PTZ actions (such as preset, patrol scan, pattern scan)
- Deep Learning Function
- Perimeter ProtectionLine crossing detection, region entrance detection, intrusion detection, region exiting detection
- Multi-Target-Type Detection
Supports simultaneous detection and capture of human body, face and vehicle,
Gets 7 face features, 14 human body features and 8 vehicle features
- Face Capture
Detects up to 30 faces simultaneously,
Uploads face with background and closed-up face pictures,Supports detecting, tracking, capturing, grading, selecting of face in motion, and outputs the best face picture
- Face Comparison
Up to 10 face libraries. 30000 faces for each library. 150000 faces in total,
Recognizes face identity via face modeling, grading and comparing to those in face library,
Supports face library encryption
- Road Traffic and Vehicle Detection
Smart Function:
Support license plate recognition of vehicles and motorcycles (only in checkpoint scenario)
Support vehicle attribute detection, including vehicle type, color, brand, driving direction, etc.
Support vehicle and non-vehicle counting
Blocklist and allowlist: up to 10,000 records
LPR Countries/Regions:
4 areas (Europe, Middle East, Asia-Pacific, Africa) and more than 124 countries/regions
Accuracy (Under recommended installation and lighting conditions):
License plate recognition rate ≥98%
Capture rate ≥99%
Driving direction accuracy rate ≥98%
Vehicle Capture Speed:
Front installation in checkpoint scenario: up to 120 km/h
Side installation: up to 80 km/h
Capture Mode: License Plate and Vehicle Mode, Vehicle Priority Mode
- Linkage and Tracking
- Smart Tracking Manual tracking, auto-tracking 3.0
- Object Tracking Support person arming. When the device detects the armed face or human body in the monitoring scene, it triggers alarms, and tracks and captures the target. During the tracking, the target location and other related information are uploaded.Support vehicle arming. When the device detects the armed vehicles in the monitoring scene, it triggers alarms, and tracks and captures the target. During the tracking, the target location and other related information are uploaded.
- General
- Power 36 VDC(Max. 60 W, including max. 12 W for IR and max. 8 W for heater), PoE 802.3bt, type3, class6 (Max. 60 W, including max. 12 W for IR and max. 8 W for heater)
- Operating Condition Temperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95%
- General Function Anti-flicker, heartbeat, mirror, flash log, password reset via e-mail, pixel counter, password protection, one-key reset, three streams
- Vandal-proof Alarm No
- Heater Yes
- De-icing No
- Demist Yes
- Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- WiperYes. Rain-sensing auto control
- Dimension Ø 267 mm × 430 mm (Ø 10.51″ × 16.93″)
- Approx. 9.6 kg (21.16 lb.)
- Protection IP67 Standard, Lightning Protection, Surge Protection and Voltage Transient Protection, ±6kV Line to Gnd, ±3kV Line to Line, IEC61000-4-5, IK10
