| Mechanical | |
|---|---|
| Dimensions | 361 x 124.6 x 71.3 mm (14.2 x 4.9 x 2.8″) |
| Weight | 752 g (1.66 lb) |
| Wind survivability | 200 km/h (125 mph) |
| Wind loading | 77 N at 200 km/h (17.3 lbf at 125 mph) |
| Hardware | |
| Networking interface | (1) GbE RJ45 port |
| Power method | Passive PoE (pairs 4, 5+; 7, 8 return) |
| Power supply | 24V, 0.3A Gigabit PoE adapter (Included) |
| Supported voltage range | 20—26V DC |
| Max. power consumption | 7.1W |
| Max. TX power | 25 dBm |
| Antenna gain | 17 dBi |
| ESD/EMP protection | Air/contact ± 24kV |
| Shock and vibrations | ETSI300-019-1.4 |
| Operating temperature | -40 to 70° C (-40 to 158° F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Operating Frequency (MHz) | |
| US/CA U-NII-1 U-NII-2A U-NII-2C U-NII-3 | 5150 – 5250 MHz 5250 – 5350 MHz 5470 – 5725 MHz 5725 – 5850 MHz |
| Worldwide | 5150 – 5875 MHz |
| Management Radio (MHz) | |
| US/CA | 2412 – 2462 MHz |
| Worldwide | 2412 – 2472 MHz |
