Product Type

• Wall AP

Radio design

• Dual-radio
  4 spatial streams
  ● 2.4 GHz: 2 x 2, MIMO
  ● 5 GHz: 2 x 2, MIMO

Maximum wireless data rate

• 1266 Mbps

6 GHz wireless data rate

• No

5 GHz wireless data rate

• 866 Mbps

2.4 GHz wireless data rate

• 400 Mbps

• Integrated 2.4 GHz and 5 GHz: 2 built-in omnidirectional antennas

Product dimensions (W x D x H)

• 86 mm x 29.3 mm x 86 mm (3.39 in. x 1.15 in. x 3.39 in.)

Color

• White

Weight

• ≤ 0.14 kg (0.31 lbs.) (without packaging materials)

Number of 10/100BASE-T ports

• 2

Power supply

• PoE/PoE+

Local power supply

• No

Dimensions of the DC connector

• No

PoE budget

• No

Maximum power consumption

• 8 W

Operating temperature

• 0°C to 40°C (32°F to 104°F)

Mounting options

• Junction box

IP rating

• IP41

Maximum number of associated wireless clients

• 64 (2.4 GHz)
  110 (5 GHz)
  110 (2.4 GHz and 5 GHz enabled)

Maximum number of devices that can be managed

• 150

• No
