- General
- Product Dimension (W × H × D)248.40 mm × 154.80 mm × 213.34 mm (9.78″× 6.09″× 8.40″)
- Package Dimension (W × H × D)306 mm × 290 mm × 59 mm (12.05″× 11.42″× 2.32″)
- Net Weight0.222 kg (0.489 lb)
- Packing List Wireless Router x 1, Ethernet cable × 1, Quick installation guide × 1
- Packing Method Single pack
- Working Temperature0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
- Working Humidity 10% to 90% RH non-condensing
- Storage Temperature-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- Storage Humidity 5% to 90% RH non-condensing
- Installation Mode Desktop installation
- Max. Power Consumption ≤ 9 W
- Gross Weight 0.722 kg (1.592 lb)
- Wireless Parameter
- Data Rate
≤ 1167 Mbps
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps
- Wireless Standard IEEE 802.11/a/n/ac wave 2 @5GHz, IEEE 802.11b/g/n @2.4GHz
- Working Frequency Band2.4 GHz，5 GHz
- Transmitting Power
CE:
<20 dBm(2.4G)
<23 dBm(5G)
- Wireless Performance
4 × 4 MU-MIMO supported
Beamforming supported
- Receiving Sensitivity
58 ± 2 dB @AC80 -MCS9
84 ± 2 dB @AC80 -MCS0
- Antenna 4 high gain antennas
- Operating Frequency
2.4 GHz: US/2412-2472 MHz(CH1-CH13)
5 GHz: US/5180-5240 MHz(CH36-CH48)
5 GHz: US/5740-5805 MHz(CH149-CH161)
- EIRP Power(Max.)
2.4 GHz: 19.86 dBm
5 GHz: 22.96 dBm
- Hardware Parameter
- Network Interface 1*10 / 100Mbps WAN port 3*10 / 100Mbps LAN ports
- LED Indicator LED indicator
- Reset Reset button
- Power Supply Method 9 VDC, 1 A power adapter power supply
- Power Specifications 9 VDC, 1 A
- Software Function
- Application function
Wireless Router Mode, Wireless Repeater Mode, Client + AP, WISP, and AP Mode supported
DHCP Server supported
Guest Network Configuration supported
Signal Adjustment supported
WiFi Schedule supported
- Security Mode WPA-PSK, WPA2-PSK, WPA and WPA2 supported
- Security Mechanism Hide SSID
- Management Method Web
- Upgrade Web Update and Upgrade
- System Log System log
