- Display
- Screen Size 2.4-inch
- Resolution 320 × 240
- Type LCD-TFT display screen
- Audio
- Audio Output 1 loudspeaker, 1 buzzer
- Network
- Wired Network TCP/IP, 10/100Mbps, self-adaptive
- Wi-Fi Support
- Interface
- Network Interface 1
- RS-485 1
- Wiegand 1
- Lock Control 1
- Exit Button 1
- Door Contact Input 1
- Alarm Input 1
- Alarm Output 1
- TAMPER 1
- USB 1
- Capacity
- Card Capacity 3000
- Fingerprint Capacity 3000
- Event Capacity 100,000
- Authentication
- Card Type EM card
- Card Reading Distance 0 to 5 cm
- Card Reading Duration＜ 1 s
- Fingerprint Module Optical fingerprint module
- Fingerprint Comparing Mode 1:1 and 1:N
- Fingerprint Recognition Duration＜ 1 s
- General
- Indicator Power/status (red/green)
- Power Supply 12 VDC/1 A
- Working Temperature -10 °C to +55 °C (14 °F to +131 °F)
- Working Humidity 10% to 90% (no condensing)
- Color Black (included), gold (optional), silver (optional), white (optional)
- Dimensions 205 mm × 76.5 mm × 37 mm (8.07″ × 3.01″ × 1.46″)
- Installation Surface mounting
- Language English, Vietnamese, Brazilian Portuguese, Spanish, French, Italian, Arabic, Thai, Turkish, Indonesian, and Ukrainian
