- System
- Operation System Linux
- Display
- Dimensions 4.3-inch
- Resolution 272 × 480
- Type LCD
- Operation Method Capacitive touch screen
- Video
- Pixel 2 MP
- Lens× 2
- Video Standard PAL (Default) and NTSC
- Network
- Wired Network 10 M/100 M self-adaptive
- Interface
- PoE IEEE 802.3at, standard PoE
- Network Interface 1
- RS-485 1
- Wiegand 1
- Lock Output 1
- Exit Button 1
- Door Contact Input 1
- TAMPER 1
- USB 1
- Capacity
- Card Capacity 3,000
- Face Capacity 1,500
- Fingerprint Capacity 3,000
- Event Capacity 150,000
- Authentication
- Card Type M1 card
- Card Reading Frequency 13.56 MHz
- Face Recognition Duration＜ 0.2 s
- Face Recognition Accuracy Rate＞99%
- Face Recognition Distance 0.3 to 1.5 m
- Fingerprint Recognition Duration＜1 s
- General
- Power Supply
Power input: Power interface (power adapter included, 12 VDC/1 A) or PoE (37 to 57 VDC/0.6 A)
Power output: Power supply for door lock, 12 VDC/1 A (only when the device is powered by PoE supporting powering supply for door lock)
- Working Temperature -30 °C to 60 °C (-22 °F to 140 °F)
- Working Humidity 0 to 90% (No condensing)
- Dimensions 91.3 mm × 181.3 mm × 24.5 mm (3.59″ × 7.14″ × 0.96″)
- Installation Wall Mounting
- Protective Level IP65
- Language English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean
- Weight
Gross weight: 0.93 kg (2.05 lbs)
Net weight: 0.36 kg (0.79 lbs)
- Function
- Face Anti-Spoofing Support
- Audio Prompt Support
- Time Synchronization Support
