- Intelligent Analytics
- AI By Device Facial recognition, perimeter protection, motion detection 2.0
- AI By Camera Facial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA
- Facial Recognition
- Facial Detection And Analytics Face picture comparison, human face capture, face picture search
- Face Picture Library Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB)
- Facial Detection And Analytics Performance 1-ch, 8 MP
- Face Picture Comparison 4-ch
- Motion Detection 2.0
- By Device All channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
- By Camera All channels
- Perimeter Protection
- By Device 2-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
- By Camera All channels
- Video And Audio
- IP Video Input 16-ch
- Incoming Bandwidth 160 Mbps
- Outgoing Bandwidth 160 Mbps
- HDMI Output 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
- VGA Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
- Video Output Mode HDMI/VGA independent output
- CVBS Output N/A
- Audio Output 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
- Two-Way Audio 1-ch, RCA (Linear, 1 KΩ)
- Decoding
- Decoding Format H.265/H.265+/H.264+/H.264
- Recording Resolution 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
- Synchronous Playback 16-ch
- Decoding Capability
AI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30 fps)
- Stream Type Video, Video & Audio
- Audio Compression G.711ulaw/G.711alaw/G.722/G.726/AAC
- Network
- Remote Connection 128
- APIONVIF (profile S/G); SDK; ISAPI
- Compatible Browser IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
- Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
- Network Interface 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- PoE
- Interface 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- Power ≤ 200 W
- Standard IEEE 802.3af/at
- Auxiliary Interface
- SATA 2 SATA interfaces
- Capacity Up to 10 TB capacity for each HDD
- USB Interface Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
- Alarm In/Out 4/1
- General
- GUI Language English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
- Power Supply 100 to 240 VAC, 50 to 60 Hz
- Consumption ≤ 15 W (without HDD and PoE off)
- Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity 10% to 90%
- Dimension (W × D × H)385 mm × 315 mm × 52 mm (15.2″× 12.4″ × 2.0″)
- Weight ≤ 3 kg (without HDD, 6.6 lb.)
- Certification
- FCC Part 15 Subpart B, ANSI C63.4-2014
- CEEN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
- Obtained Certification CE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS
