- General
- Product Dimension (W × H × D) 241.3 mm × 140.8 mm × 156.3mm
- Package Dimension (W × H × D) 380 mm × 285 mm × 73 mm
- Net Weight0.245 kg
- Packing List
1500Mbps Wi-Fi6 Router x 1
Power Supply Adaptor × 1
CAT5e Network Cable × 1
Quick Start Guide × 1
Regulatory Compliance and Safety Information × 1
- Packing Method Single pack
- Working Temperature 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
- Working Humidity 10% to 90% RH non-condensing
- Storage Temperature -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- Storage Humidity 5% to 95% RH non-condensing
- Installation Mode Desktop installation
- Max. Power Consumption ≤ 10 W
- Gross Weight 0.790 kg
- Wireless Parameter
- Data Rate ≤ 1501 Mbps
5GHz: 1201Mbps
2.4GHz: 300Mbps
- Wireless Standard
IEEE 802.11a/n/ac/ax @5GHz
IEEE 802.11b/g/n @2.4GHz
- Transmitting Power
CE:
＜20dBm(2.4GHz)
＜23dBm(5GHz)
- Wireless Performance
MU-MIMO supported
TxBeamforming supported
- Receiving Sensitivity
5GHz:
-89dBm@HE80-MCS0
-60dBm@HE80-MCS11
2.4GHz:
-93dBm@HT40-MCS0
-73dBm@HT40-MCS7
- Antenna 4 high gain antennas
- Hardware Parameter
- Network Interface
1 × 10/100/1000 Mbps Adaptive WAN Port
3 × 10/100/1000 Mbps Adaptive LAN Ports
- LED Indicator LED indicator
- Reset Reset button
- Power Supply Method Power Supply Adapter
- Power Specifications DC 12 V, 1 A
- Software Function
- Application function
Routing Mode, Wireless Relay Mode, Wired Bridge Mode supported
DHCP Server supported
Guest Network Configuration supported
Signal Adjustment supported
WiFi Schedule supported
Daylight Saving Time supported
- Security Mode WPA2-PSK,WPA/WPA2-PSK,WPA2-PSK/WPA3-SAE supported
- Security Mechanism
Support fast and secure WPS connection
Support hiding wireless network name
Support controlling terminal network connection
Support firewalls
- Management Method Web, HIK-Connect APP
- Upgrade Web, App Update and Upgrade
- System Log System log
