- Camera
- Image Sensor 2 MP CMOS
- Max. Resolution 1920 (H) × 1080 (V)
- Min. Illumination 0.01 Lux @(F1.6, AGC ON), 0 Lux with White Light
- Shutter Time PAL: 1/12.5 s to 1/50,000 s ,NTSC: 1/15 s to 1/50,000 s
- Day & Night ICR
- Angle Adjustment Pan: 0° to 360°,Tilt: 0° to 75°,Rotate: 0° to 360°
- Signal System PAL/NTSC
- Lens
- Lens Type 2.8 mm
- Focal Length & FOV
2.8 mm, horizontal FOV: 105°, vertical FOV: 59°, diagonal FOV: 127°;
- Lens Mount M12
- Microphone
- Pickup Distance In a radius of up to 5 m
- Amount1
- Speaker
- Rated Power 2 W
- Speaker Range In a radius of up to 5 m
- Illuminator
- Supplement Light Type
IR, White Light
- Supplement Light Range IR: Up to 40 m, White Light: Up to 40 m
- Image
- Image Settings
Anti-banding, Brightness, Sharpness, Smart IR
- Frame Rate TVI: 1080p @25 fps/30 fps
- Day/Night Mode Auto/Color/BW (Black and White)
- Wide Dynamic Range (WDR) Digital WDR
- Image Enhancement
DWDR, BLC, HLC, Global, HLS
- Noise Reduction 2D DNR
- White Balance
Auto, Manual
- Audio
- Audio Function Echo Cancellation, AI Noise Reduction, Automatic Gain Control
- Interface
- Video Output 1 HD analog output
- Alarm Flashing Light Alarm (Red & Blue)
- General
- Power 12 VDC ± 25%, max.8.5 W
- Material Main body: Metal; Enclosure: Plastic
- Dimension Ø110 mm × 102.7 mm (Ø4.33″ × 4.04″)
- Weight Approx. 385 g (0.85 lb.)
- Operating Condition -40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
- Communication HIKVISION-C
- Language English
- Approval
- Protection IP67
