- Camera
- Image Sensor 2 MP CMOS
- Max. Resolution 1920 (H) × 1080 (V)
- Min. Illumination 0.01 Lux @ (F2.0, AGC ON), 0 Lux with white light
- Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
- Day & Night ICR
- Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
- Signal System PAL/NTSC
- Lens
- Lens Type Fixed focal lens, 2.8 mm, 3.6 mm and 6 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°
3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°
6 mm, horizontal FOV: 49.2°, vertical FOV:28.3 °, diagonal FOV: 56.1°
- Lens Mount M12
- Illuminator
- Supplement Light Type White Light ;IR
- Supplement Light Range
IR : Up to 60 m
White Light : Up to 60 m
- Image
- Image Settings Anti-Banding, Brightness, Sharpness, Smart IR
- Frame Rate
TVI: 1080P @ 30 fps, 1080P @ 25 fps
AHD: 1080P @ 30 fps, 1080P @ 25 fps
CVI: 1080P @ 30 fps, 1080P @ 25 fps
CVBS: PAL/NTSC
- Day/Night Mode Auto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)Digital WDR
- Image Enhancement DWDR/BLC/HLC/Global
- White Balance Auto/Manual
- AGC Yes
- Interface
- Video Output Switchable TVI/AHD/CVI/CVBS
- General
- Power 12 VDC ± 25%, max.9.8 W,*You are recommended to use one power adapter to supply the power for one camera.
- Material
Front cover: Metal
Main body: Plastic
- Dimension 192.6 mm × 178.3 mm × 71 mm (7.58″ × 7.02″ × 2.8″)
- Weight Approx. 738 g (1.63 lb.)
- Operating Condition -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- Communication HIKVISION-C
- Language English
- Approval
- Protection IP67
