- Camera
- Image Sensor 1/2.8″ Progressive Scan CMOS
- Min. Illumination Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR
- Shutter Speed 1/3 s to 1/100,000 s
- Slow Shutter Yes
- Day & Night IR cut filter
- Wide Dynamic Range Digital WDR
- Lens
- Lens Fixed lens, 2.8
- Auto-Iris No
- Aperture F2.0
- FOV2.8mm: Horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135° ;4 mm: Horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102°
- Lens Mount M12
- Illuminator
- IR Range Up to 30 m
- Wavelength 850 nm
- Video
- Max. Resolution 1920 × 1080
- Video Compression Main stream: H.265+/H.265/H.264+/H.264;Sub-stream: H.265/H.264/MJPEG
- H.264 Type Baseline Profile/Main Profile/High Profile
- H.265 Type Main Profile
- Video Bit Rate 32 Kbps to 8 Mbps
- Smart Feature-Set
- Region Of Interest1 fixed region for main stream and sub-stream
- Image
- Image Enhancement BLC, 3D DNR
- Image Setting Rotate mode, saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser
- Day/Night Switch Day/Night/Auto/Schedule
- Main Stream Max. Frame Rate50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720);60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
- Sub-Stream Max. Frame Rate50Hz: 25fps (640 × 480, 640 × 360, 320 × 240);60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
- Network
- Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
- APIONVIF (PROFILE S, PROFILE G), ISAPI
- Simultaneous Live View Up to 6 channels
- User/Host Up to 32 users,3 levels: Administrator, Operator, and User
- ClientiVMS-4200, Hik-Connect, iVMS-5200
- Web Browser IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
- Alarm Trigger Motion detection, video tampering alarm, illegal login
- Interface
- Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
- General
- Firmware Version5.5.83
- General Function One-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Startup And Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
- Power Supply12 VDC ± 25%, Φ 5.5 mm coaxial power plug; PoE (802.3af, class 0)
- Material Camera body: metal, bottom base : plastic
- Dimensions Camera: 94.4 × Φ110 mm (3.7″ × Φ4.3″) ;With package: 150 × 150 × 141 mm (5.9″ × 5.9″ × 5.6″)
- Camera: Approx. 354 g (0.8 lb.) ;With package: Approx. 681 g (1.5 lb.)
- Power Consumption And Current12 VDC, 0.4 A, max. 5 W; PoE (802.3af, 36 V to 57 V), 0.20 A to 0.10 A, max. 6.5 W
- Interface Protection Ingress protection: IP66 (IEC 60529-2013)
