Mercusys MW302R

Wireless Standards IEEE 802.11b/g/n

Frequency 2.4-2.4835GHz

Signal Rate

• 11n: Up to 300Mbps (Dynamic)

• 11g: Up to 54Mbps (Dynamic)

• 11b: Up to 11Mbps (Dynamic)

Reception Sensitivity

• 270M: -73dBm@10% PER

• 130M: -75dBm@10% PER

• 54M: -77dBm@10% PER

• 11M: -90dBm@10% PER

• 6 M: -94dBm@10% PER

• 1 M: -96dBm@10% PER

Transmission Power <20dBm (EIRP)

Wireless Security WPA-PSK / WPA2-PSK

Wireless Functions

Enable/Disable Wireless Radio, WDS Bridging Software

WAN Type Dynamic IP/Static IP/PPPoE/PPTP/L2TP

Management Access Control, Local Management, Remote Management

DHCP Server

Port Forwarding Virtual Server, UPnP, DMZ

Firewall Security

IP and MAC Address Binding

Protocols IPv4, IPv6

Guest Network 2.4GHz Guest Network

Hardware

Dimensions (W X D X H)

114 mm × 94 mm × 26 mm

Button Reset Button

External Power Supply  5V/0.6A

Antenna Type 2 * 5dBi

Ethernet Ports

2*10/100Mbps LAN Ports &

1*10/100Mbps WAN Port

Environment

• Operating Temperature: 0°C~40°C (32°F~104°F)

• Storage Temperature: -40°C~70°C (-40°F~158°F)

• Operating Humidity: 10%~90% Non-Condensing

• Storage Humidity: 5%~90% Non-Condensing
