- General
- Product Dimension (W × H × D)174.82 mm × 96.45 mm × 181.06 mm (6.88″× 3.80″× 7.13″)
- Package Dimension (W × H × D)231 mm × 203 mm × 51 mm (9.09″× 7.99″× 2.01″)
- Net Weight 0.134 kg (0.295 lb)
- Packing List Wireless Router x 1, Ethernet cable × 1, Quick installation guide × 1
- Packing Method Single pack
- Working Temperature 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
- Working Humidity 10% to 90% RH non-condensing
- Storage Temperature -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- Storage Humidity 5% to 90% RH non-condensing
- Installation Mode Desktop installation
- Max. Power Consumption ≤ 5.4 W
- Gross Weight 0.634 kg (1.398 lb)
- Wireless Parameter
- Data Rate 2.4 GHz: 300 Mbps
- Wireless Standard IEEE 802.11b/g/n @2.4 GHz
- Transmitting Power 18 dBm
- Wireless Performance Beamforming supported
- Receiving Sensitivity
58 ± 2 dB@AC80 -MCS9
84 ± 2 dB@AC80 -MCS0
- Antenna 2 high gain antennas
- Hardware Parameter
- Network Interface 4 × RJ45, 10/100 Mbps auto-negotiation
- LED Indicator LED indicator
- Reset Reset button
- Power Supply Method 9 VDC, 1 A power adapter power supply
- Power Specifications 9 VDC, 1 A
- Software Function
- Application function
Wireless Router Mode, Wireless Repeater Mode, Client + AP, WISP, and AP Mode supported
DHCP Server supported
Guest Network Configuration supported
Signal Adjustment supported
WiFi Schedule supported
- Security Mode WPA-PSK/WPA2-PSK, WPA/WPA2
- Security Mechanism Hide SSID
- Management Method Web
- Upgrade Web Update and Upgrade
- System Log System log
- WAN Mode DHCP,Static IP,PPPoE
