- General
- Core Color 1 Blue & White / Blue 2 Orange & White / Orange,3 Green & White / Green 4 Brown & White / Brown,
- PackingCarton
- Carton Dimension 41x 41x 24cm
- Packing length (305±1.5) m
- Rip-cord Yes
- Drain wire No
- Sheath Physical Properties Before Aging Tensile Strength (Mpa) ≥13.5, Elongation (%) ≥ 150, Aging Period (℃×hrs) 100
- ℃×24h× 7d, After Aging ,Tensile Strength (Mpa) ≥ 12.5, variance ratio: ± 25 %, Elongation (%) ≥ 125, variance ratio: ± 20 % ,Cold bend (-20±2℃×4h) 8×Cable O.D. ，No visible cracks,
- Electrical Characteristics (20℃) 1.0-100.0 MHz Impedance (Ω) 100±15,100 – 250MHz Impedance (Ω) 100±25,1.0-100.0MHz Delay Shew (ns/100m) ≤45,DC Resistance Ω /100m) max 12 ,DC Conductor Resistance Unbalance (%) max 2,
- Conductor
- Material CCA （Copper content：27%）
- Nom. O.D.(mm)0.585±0.01
- Insulation
- Material Solid HDPE
- Diameter 1 .05±0.05mm
- Sheath
- Thickness 0.50 ± 0.05 mm
- External O.D.6.0 ±0 .30 mm
- Surface Clean, Frap, Satiation
- Material FR-PVC (complies RoHS)
- Color White RAL 9003
- Surface Printing
- Letter height 2.5 ± 0.2mm
- Color Black
- Print error & Space ≤±0.5%，1m
