Name: Hikvision DS-2CD1323G0E-I
SKU: DS-2CD1323G0E-I
Availability: InStock

Hikvision DS-2CD1323G0E-I

Camera
Image Sensor 1/2.8″ progressive scan CMOS
Min. Illumination Color: 0.01Lux @(F1.2, AGC ON),0 Lux with IR
Shutter Speed 1/3s to 1/100,000 s, support slow shutter
Lens 2.8 mm @F2.0, horizontal field of view 95°
Lens Mount M12
Day & Night IR cut filter with auto switch
3-Axis Adjustment Pan: 0° to 360°, tilt: 0°to 75°, rotation:0° to 360°
DNR (Digital Noise Reduction) 3D DNR
WDR (Wide Dynamic Range) Digital WDR
Compression Standard
Video Compression Main stream: H.264+/H.264
Sub stream: H.264/MJPEG
H.264 Type Baseline Profile/Main Profile
Video Bit Rate 32 Kbps to8 Mbps
Max. Resolution 1920 × 1080
Main Stream
Max. Frame Rate
50Hz: 25fps @(1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps @(1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream
Max. Frame Rate
50Hz: 25fps @(704 × 576, 640 × 480, 352 × 288,320 × 240)
60Hz: 30fps @(704 ×480, 640 × 480, 352 × 240,320 × 240)
Image Settings Brightness, saturation, contrast, sharpness are adjustable via web browser or client software
Day/Night Switch Support auto, scheduled
Others Mirror, BLC (area configurable), region of interest (support 1 fixed region)
Network
Network Storage NAS (NFS,SMB/CIFS)
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP,
802.1X, QoS, IPv6, Bonjour
Standard ONVIF(PROFILE S,PROFILE G),PSIA,CGI,ISAPI
General Function Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Interface
Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
General
Operating Conditions -30 °C to60 °C (-22 °F to140 °F), humidity: 95% or less (non-condensing)
Power Supply 12VDC± 25%, PoE (802.3af)
Power Consumption Max. 4 W/6 W (PoE)
Ingress Protection IP67
IR Range Up to 30 m
Dimensions Φ 85.5 mm × 70 mm (3.38″× 2.76″)
Weight 350 g (0.77 lb.)
