| Specifications |
|---|
| Model | CS-EB3 (3MP) |
|---|
| Camera |
|---|
| Image Sensor | 1 / 2.8” 3-Megapixel Progressive Scan CMOS Sensor |
|---|
| Minimum Illumination | 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR |
|---|
| Shutter Speed | Self-adaptive shutter |
|---|
| Lens | 2.8mm @ F2.0; 131° (Diagonal), 110° (Horizontal), 58° (Vertical) |
|---|
| Day & Night | IR-Cut filter with auto-switching |
|---|
| DNR | 3D DNR |
|---|
| Night Vision | IR Distance : 15m, Color Night Vision Distance:15m |
|---|
| Video & Audio |
|---|
| Max. Resolution | 2304 × 1296 |
|---|
| Frame Rate | 15 fps. Self-Adaptive during network transmission |
|---|
| Video Compression | H.265 / H.264 |
|---|
| Video Bit Rate | Quad HD; Full HD, Hi-Def. Adaptive bit rate |
|---|
| Audio Bit Rate | Self-Adaptive |
|---|
| Max. Bitrate | 1.5 Mbps |
|---|
| Network |
|---|
| Wi-Fi Standard | IEEE 802.11b, 802 .11g, 802 .11n |
|---|
| Frequency Range | 2.4 GHz ~ 2.4 835 GHz |
|---|
| Channel Bandwidth | Supports 20 MHz |
|---|
| Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
|---|
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps |
|---|
| Wi-Fi Pairing | AP pairing |
|---|
| Protocol | EZVIZ cloud proprietary protocol |
|---|
| Interface Protocol | EZVIZ cloud proprietary protocol |
|---|
| Minimum Network Requirement | 4Mbps |
|---|
| Function |
|---|
| Smart Alarm | Smart Human Motion Detection |
|---|
| Customized Alert Area | Supports |
|---|
| Two-way Talk | Supports |
|---|
| General Function | Anti-Flicker, Heart Beat, Password Protection, Watermark |
|---|
| Storage |
|---|
| Local Storage | Supports microSD Card (Up to 256 GB) |
|---|
| Cloud Storage | Supports EZVIZ Cloud Play storage (Subscription required) |
|---|
| General |
|---|
| Operating Conditions | -20 °C to 50 °C (-4 °F to 122 °F ), humidity 95% or less (Non-condensing) |
|---|
| IP Grade | Weatherproof Design |
|---|
| Power Supply | DC 5V / 2A (Purchased Separately) |
|---|
| Battery Capacity | 5200 mAh |
|---|
| Power Consumption | Max. 10W |
|---|
| Product Dimensions | 105.9 × 62.8 × 62.8 mm (4.17 × 2.47 × 2.47 inch) |
|---|
| Packaging Dimensions | 103 × 103 × 186 mm (4.06 × 4.06 × 7.32 inch) |
|---|
| Weight | 522 g ( 18.41 oz ) |
|---|
| In the box |
|---|
| In the box | – EB3 Camera |
|---|
| – Screw Base |
| – USB Cable |
| – Mounting plate |
| – Drill Template |
| – Screw Kit |
| – Regulatory Information |
| – Quick Start Guide |
| Certifications |
|---|
| Certifications | CE / FCC / UKCA / WEEE / RoSH / REACH |
|---|
