| Specifications |
|---|
| Model | CS – CB2 -R 100 -2D 2WF |
|---|
| Camera |
|---|
| Image Sensor | 1 / 2.8” 2-Megapixel Progressive Scan CMOS Sensor |
|---|
| Shutter Speed | Self-Adaptive Shutter |
|---|
| Lens | 4 mm @ F1.6, view angle: 100°, 85° (Diagonal), 46° (Horizontal) |
|---|
| Night Vision | Max. 5 m / 16 ft |
|---|
| Minimum Illumination | 0.1 Lux |
|---|
| Lens Mount | M 12 |
|---|
| Day & Night | IR-cut Filter with Auto Switch |
|---|
| DNR | 3D DNR |
|---|
| Network |
|---|
| Wi-Fi Standard | IEEE 802.11 b, 802.11g, 802.11n |
|---|
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
|---|
| Channel Bandwidth | Supports 20 MHz |
|---|
| Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
|---|
| Transmission Rate | 11 b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
|---|
| Wi-Fi Pairing | AP pairing |
|---|
| Protocol | EZVIZ Cloud Proprietary Protocol |
|---|
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
|---|
| Wired Network | Does not support |
|---|
| Minimum Network Requirement | 1 Mbps |
|---|
| Video & Audio |
|---|
| Max. Resolution | 1920 × 1080 |
|---|
| Frame Rate | 15 fps. Self-Adaptive during Network Transmission |
|---|
| Video Compression | H.265 / H.264 |
|---|
| Video Bit Rate | Full HD; Hi-Def; Standard |
|---|
| Audio Bit Rate | Self-Adaptive |
|---|
| Max. Bitrate | 1 Mbps |
|---|
| Function |
|---|
| Smart Alarm | Supports smart human motion detection |
|---|
| Customized Alert Area | Supports |
|---|
| Two-way Talk | Supports |
|---|
| Storage |
|---|
| Local Storage | Supports micro SD card (Up to 512 GB) |
|---|
| Cloud Storage | Supports EZVIZ Cloud Play storage (subscription required) |
|---|
| General |
|---|
| Operating Conditions | -10° C to 45° C (14°F to 113 °F ), Humidity 95% or Less (Non-condensing) |
|---|
| Power Supply | DC 5V / 1A (Purchased Separately) |
|---|
| Battery Capacity | 2000 mAh |
|---|
| Dimensions | 50.5 × 39.1 × 39.1 mm (1.99 ×1.54 × 1.54 inch) |
|---|
| Packaging Dimensions | 126 × 91× 50 mm (4.96 × 3.58 × 1.97 inch) |
|---|
| Net Weight | 86.8 g (3.06 oz) |
|---|
| With Package | 273g (9.63 oz) |
|---|
| In the box |
|---|
| In the box | – CB2 Camera |
|---|
| – Magnetic Base |
| – Power Cable |
| – Foam Sticker |
| – Mounting Metal Plate |
| – Regulatory Information |
| – Quick Start Guide |
| Certifications |
|---|
| Certifications | CE / WEEE / RoHS / REACH / UL |
|---|
