TP-Link EAP772-Outdoor BE11000 WiFi 7 Access Point

TP-Link EAP772-Outdoor BE11000 Tri-Band WiFi 7 Access Point

The TP-Link EAP772-Outdoor is a professional indoor and outdoor access point designed for hotels, business parks, farms, courtyards, and demanding commercial networks. Combining tri-band WiFi 7, omnidirectional antennas, IP68 weather protection, and Omada management, it helps organizations extend managed wireless connectivity beyond indoor rooms. A compatible wired network and internet gateway are required because this device functions as an access point rather than a standalone modem or router.

BE11000 Tri-Band WiFi 7 Performance

The documented BE11000 configuration provides theoretical wireless rates up to 5765Mbps on 6GHz, 4324Mbps on 5GHz, and 688Mbps on 2.4GHz. These rates total approximately 10.8Gbps across three bands, not a guaranteed speed for one user. Actual throughput varies with clients, interference, channel availability, distance, and the 2.5Gbps wired uplink. Regional variants and approved frequency settings may change available performance.

Outdoor 6GHz and AFC Requirements

The additional 6GHz band can provide less congested spectrum for compatible clients where regulations allow its operation. TP-Link highlights Automated Frequency Coordination, or AFC, for authorized outdoor 6GHz deployments. Availability depends on the country, regulatory approval, location, firmware, and permitted channels. Buyers in Pakistan should verify current local rules and TP-Link regional support before advertising outdoor 6GHz operation as enabled.

Multi-Link Operation and Advanced Features

Multi-Link Operation allows supported WiFi 7 devices to use multiple wireless links, potentially improving responsiveness and resilience. The access point also offers 320MHz channel capability on 6GHz, 4K-QAM, Multi-RU, OFDMA, and MU-MIMO. These technologies can improve efficiency when compatible clients operate under suitable signal conditions. Older wireless devices can connect using supported legacy standards without gaining every WiFi 7 enhancement.

Omnidirectional Coverage for Open Areas

Unlike a focused point-to-point bridge, the EAP772-Outdoor distributes wireless signals around its mounting position. TP-Link recommends coverage of approximately 300 square meters under laboratory conditions and rates the unit for more than 380 connections. Its 2.4GHz dual-polarized antenna design helps address outdoor signal challenges. Actual coverage and useful client capacity depend on obstacles, mounting height, interference, and traffic demands. For best results, select mounting positions that provide a clear radio path to the areas people actually use, including entrances, seating areas, and courtyards.

IP68 Weatherproof Outdoor Construction

An IP68-rated sealed enclosure provides protection against dust and water immersion under specified testing conditions. It is designed for challenging outdoor installations, but correct waterproof sealing, grounding, suitable cabling, and surge protection remain essential. Included wall and pole mounting kits enable flexible placement on supported structures. Installers should survey the location and plan safe access for future maintenance.

2.5Gbps Ethernet and PoE Power

One 2.5Gbps RJ45 interface provides wired network connectivity and accepts IEEE 802.3at PoE+. A compatible multi-gigabit PoE+ switch or injector can supply data and power over one suitable cable. TP-Link lists maximum PoE consumption of 23W on its Pakistan product page. The standard accessories include waterproof and mounting kits, but no DC power adapter is specified.

Omada Management and Guest Security

Compatible Omada controllers support centralized monitoring, configuration, mesh, seamless roaming, and remote management. Businesses can configure up to twenty-four SSIDs across three bands, with VLAN mapping, client isolation, captive portals, and WPA3 security. Some advanced features require a controller and appropriate upstream network configuration.

Buy TP-Link EAP772-Outdoor in Pakistan

Choose the TP-Link EAP772-Outdoor for advanced wireless coverage in hospitality venues, commercial yards, and managed outdoor spaces. Explore Smartlinks.pk for price, stock, and warranty information. Network planners should also consider peak attendance, future expansion, outdoor cable routes, and the switching capacity needed to support several access points during busy periods. Confirm your regional BE11000 version, 6GHz authorization, suitable PoE equipment, and mounting requirements before purchasing.
