TP-Link EAP115-Wall N300 WiFi Access Point

Key Product Highlights

300Mbps Wireless N: Up to 300Mbps theoretical wireless speed on 2.4GHz.
Wall-Plate Design: Fits compatible standard EU-style or 86mm wall junction boxes.
2.4GHz Wireless Connectivity: Supports IEEE 802.11b/g/n devices.
Dual Internal Antennas: Two 1.8dBi omnidirectional antennas for room-level coverage.
Two Fast Ethernet Ports: One 10/100Mbps uplink and one 10/100Mbps downlink.
IEEE 802.3af PoE: Power and data through a compatible Ethernet connection.
Low Power Consumption: Maximum rated consumption of 2.8W.
Omada Centralized Management: Manage compatible access points through supported Omada controllers.
Captive Portal Authentication: Useful for managing guest wireless access.
Multiple SSIDs: Supports up to eight wireless network names.
SSID-to-VLAN Mapping: Helps separate wireless networks for different users.
LAN Port VLAN Configuration: Supports network segmentation for the wired downlink.
Client Isolation: Helps restrict communication between connected wireless clients.
Bandwidth Rate Limiting: Controls network resource usage.
Wireless Scheduling: Configure supported operating periods.
Guest Room Coverage: Manufacturer-tested coverage of approximately 25m², subject to environmental conditions.
Compact Installation: Suitable for hotels, offices, apartments, and individual rooms.

Discover More: TP-Link Access Points

10 People watching this product now!

Compare

Add to wishlist

Description

TP-Link EAP115-Wall 300Mbps Wireless N Wall-Plate Access Point

The TP-Link EAP115-Wall is a compact indoor access point designed to provide convenient wireless connectivity in hotel bedrooms, apartments, offices, and other individual rooms. Its discreet wall-plate enclosure replaces a compatible data socket faceplate, helping businesses expand WiFi coverage without installing bulky ceiling equipment. Featuring 2.4GHz Wireless N, standard PoE, and Omada management, it offers practical networking for properties that already have Ethernet cabling.

Reliable 300Mbps Wireless N Connectivity

The EAP115-Wall supports IEEE 802.11b/g/n standards and offers theoretical wireless link rates up to 300Mbps on the 2.4GHz band. This frequency supports common smartphones, laptops, and connected equipment, although nearby wireless networks can create congestion. Advertised link rates are not guaranteed download speeds. Actual performance depends on interference, client capabilities, room layout, internet service, and the 100Mbps Ethernet uplink.

Designed for Individual Room Coverage

Two internal 1.8dBi omnidirectional antennas distribute wireless coverage around the installation area. TP-Link lists approximately 25 square meters of coverage under test conditions, making the unit particularly relevant for guestrooms and compact offices. Thick walls, metal furniture, and competing networks may reduce its useful coverage. For larger premises, deploy multiple units in appropriately selected rooms rather than expecting one wall-mounted access point to serve an entire floor.

Convenient Wall-Plate Installation

The access point mounts into a compatible EU-style or 86mm wall junction box using existing network wiring. Its low-profile appearance fits professional interiors without prominent antenna rods or complicated brackets. Installation involves connecting the incoming Ethernet cable, fastening the unit, and fitting the cover securely. Check junction-box dimensions, cable termination, and installation clearances before purchasing.

Standard IEEE 802.3af PoE Power

Power over Ethernet allows the EAP115-Wall to receive electrical power and network data through its uplink cable. A compatible IEEE 802.3af PoE switch or injector can simplify installation by eliminating a separate electrical outlet at the wall plate. Maximum rated power consumption is only 2.8W. Always confirm the power source is compatible; standard PoE input must not be confused with PoE output for other equipment.

Two Fast Ethernet Ports

The device provides one 10/100Mbps uplink port and one 10/100Mbps downlink port. The uplink connects to the existing wired network and receives power, while the downlink can connect suitable wired equipment in the room. Neither port is Gigabit Ethernet. Customers requiring faster wired connectivity or modern dual-band performance should consider an appropriate higher-specification wall-plate access point instead.

Omada Centralized Management

With compatible Omada hardware or software controllers, administrators can configure, monitor, and maintain multiple access points centrally. Supported settings include device status monitoring, wireless configuration, management VLANs, and network diagnostics. Cloud access requires a suitable controller configuration. The Omada app can help manage supported deployments, while available functions depend on controller software and device firmware.

Guest WiFi and Network Security

The EAP115-Wall supports up to eight SSIDs for different groups of users. Captive portal authentication, wireless client isolation, access controls, MAC filtering, rate limits, and SSID-to-VLAN mapping can help organize guest connectivity. Local LAN port VLAN configuration supports additional segmentation. Administrators must also configure upstream switches and gateways correctly for meaningful network separation and security.

Buy TP-Link EAP115-Wall in Pakistan

The TP-Link EAP115-Wall is suitable for room-by-room business WiFi where discreet mounting, standard PoE, and centralized administration matter. It operates only at 2.4GHz and is not a replacement for an internet router. Explore Smartlinks.pk for availability, pricing, and warranty details. Confirm the hardware revision, junction-box compatibility, and included accessories before ordering.

For larger hotel projects, plan switch capacity and cabling carefully, and confirm the number of room units required before deployment.
