- Motion Detection 2.0
- Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
- Perimeter Protection
- Human/Vehicle Analysis Up to 4-ch
- Recording
- Video Compression H.265 Pro/H.265
- Encoding Resolution
When 1080p Lite mode is not enabled:
5MPLite/3K/4MPLite/1080p/1080pLite/720p/WD1/4CIF;
When 1080p Lite mode is enabled:
5MP/3KLite/4MPLite/1080p Lite/720p/WD1/4CIF;
- Frame Rate
Main stream:
When 1080p lite mode not enabled:
For 5MP stream access:
3K/5MPLITE @12FPS；4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
For 1080p stream access:
1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
When 1080p Lite mode enabled:
5MP/3K lite/ 4 MP lite/3 MP@15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 fps (P)/30fps (N)
- Video Bitrate According to the actual scene, scene-adaptive bitrate control technology would automatically allocates appropriate bitrate to ensure the stability of recording period.
- Stream Type
Video, Video & Audio
Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.
- Audio Compression G.711u
- Audio Bitrate 64 Kbps
- Video And Audio
- IP Video Input 2-ch Up to 6 MP resolution
Support H.265+/H.265 IP cameras
- Analog Video Input
8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI Input 3K@20 fps, 5 MP@20 fps, 4 MP@30 fps, 4 MP@25 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps, 720p50, 720p60
- AHD Input 5 MP@20 fps, 4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
- HDCVI Input 5 MP@20 fps, 4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
- CVBS Input Support
- HDMI Output 1-ch, 1920 Ă— 1080/60 Hz, 1280 Ă— 1024/60 Hz, 1280 Ă— 720/60 Hz
- VGA Output 1-ch, 1920 Ă— 1080/60 Hz, 1280 Ă— 1024/60 Hz, 1280 Ă— 720/60 Hz
- Video Output Mode HDMI/VGA simultaneous output
- Audio Input 8-ch via coaxial cable
- Audio Output 1-ch via HDMI
- Synchronous Playback 4-ch
- Network
- Total Bandwidth 96 Mbps
Incoming bandwidth: 8 Mbps
- Remote Connection 64
- Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
- Network Interface 1, RJ45 10/100 Mbps self-adaptive Ethernet interface
- Auxiliary Interface
- Capacity Built-in 1024 GB eSSD (960 GB available)
Note: The device can store about 2 weeks videos for 8-ch analog cameras (default parameters), this estimation is for reference only.
- Alarm In/Out OPTIONAL 4/1
- USB Interface Rear panel: 2 Ă— USB 2.0
- General
- Power Supply 12 VDC, 1 A
- Consumption ≤ 8.2 W (with eSSD)
- Working Temperature -10 °C to 45 °C (14 °F to 113 °F)
- Working Humidity 10% to 90%
- Dimension (W Ă— D Ă— H)170 Ă— 121.6 Ă— 46 mm (6.7 Ă— 4.79 Ă— 1.81 inch)
- Weight ≤ 0.5 kg (with eSSD, 1.1 lb.)
