TP-Link TL-SG1008P 8-Port Gigabit Desktop PoE+ Switch – 64W Power Budget, 4 PoE+ Ports & CCTV Support

TP-Link TL-SG1008P 8-Port Gigabit PoE+ Switch

The TP-Link TL-SG1008P is an unmanaged Gigabit desktop switch designed for small offices, shops, CCTV installations, and home networks. It combines eight Ethernet connections with four PoE+ ports, allowing compatible cameras, access points, and IP phones to receive network data and power through one cable. This reduces adapters and helps create a tidier wired installation. The following specifications describe the V6 version listed on Smartlinks Pakistan.

Eight Gigabit Ethernet Ports

All eight RJ45 interfaces support 10/100/1000Mbps speeds and automatic negotiation. Ports one through four can deliver PoE+ power, while ports five through eight provide data connectivity only. Connect a router, network video recorder, printer, or computer to ports according to your layout. Because every port supports Gigabit Ethernet, the switch can accommodate devices and local data transfers. Throughput depends on cable quality, connected hardware, and overall traffic.

Four PoE+ Connections

The four powered ports support IEEE 802.3af/at, with up to 30W available from each port. However, the combined PoE budget is limited to 64W. Four devices cannot each consume 30W simultaneously. Before installation, check power ratings, including camera infrared lighting, pan-and-tilt motors, and startup demands. Devices requiring passive PoE or incompatible power standards need alternative equipment. The remaining four ports cannot power connected devices.

Intelligent Power Management

Power management monitors the total electricity requested by connected PoE equipment. If demand exceeds the 64W budget, the switch can disconnect lower-priority PoE ports to protect higher-priority connections and prevent overload. This protection does not eliminate the need for careful planning. Leave headroom for changing power requirements and test cameras after night vision activates. Confirm the supplied power adapter matches your hardware revision.

Efficient Switching Performance

A manufacturer-rated 16Gbps switching capacity and 11.904Mpps forwarding rate support simultaneous Ethernet traffic across the eight ports. The switch uses store-and-forward transmission, a 4K MAC address table, and IEEE 802.3x flow control. Automatic MAC learning helps direct frames toward the intended destination. These features support office work, local file sharing, and suitable surveillance traffic without requiring a managed configuration interface.

QoS and Multicast Handling

Built-in 802.1p/DSCP Quality of Service helps prioritize latency-sensitive traffic such as voice calls and video communication. IGMP Snooping can reduce unnecessary multicast distribution for supported applications. These features offer basic traffic optimization, but this remains an unmanaged switch. It does not provide administrator-configurable VLANs, remote port monitoring, or Omada controller management. Select a managed model if your installation needs those capabilities.

Plug-and-Play Installation

No software, license, or controller is necessary. Connect the included adapter, attach Ethernet cables, and confirm active connections using the indicator lights. Auto MDI/MDIX makes ordinary cable selection easier, while the fanless metal enclosure operates quietly near desks or recording equipment. The compact housing supports desktop placement and suitable wall mounting. Keep ventilation clear, avoid moisture, and label cables for troubleshooting.

CCTV and Office Applications

The TL-SG1008P can connect compatible IP cameras, wireless access points, VoIP phones, computers, and network recorders. Its Gigabit ports are useful when multiple devices share an uplink, but a successful design still depends on recording bitrate, available ports, and PoE demand. Use Cat5e or better cable for reliable Gigabit links within standard Ethernet distances. This model does not advertise 250-meter Extend Mode or automatic PoE recovery on the documented V6 configuration.

Buy TP-Link TL-SG1008P in Pakistan

For small installations that need four PoE+ outputs and four additional Gigabit connections, the TL-SG1008P is a practical choice. Before purchasing from Smartlinks Pakistan, confirm your hardware version, stock availability, warranty, and peak power requirements. Older V3 units provide a different 55W PoE budget, so do not assume every TL-SG1008P has identical specifications.
