TP-Link TL-SG1005P 5-Port Gigabit PoE Switch – 4 PoE Ports, 56W Power Budget, Plug & Play Ethernet Switch

TP-Link TL-SG1005P 5-Port Gigabit PoE Switch

The TP-Link TL-SG1005P is a compact unmanaged Gigabit switch designed for small offices, retail counters, CCTV systems, and home networks. It provides five Ethernet ports, including four Power over Ethernet connections that deliver data and electricity through compatible network cables. This arrangement helps installers reduce separate adapters for supported IP cameras, access points, and VoIP phones. The following details describe the earlier V1 hardware version listed by Smartlinks Pakistan.

Five Gigabit Ethernet Connections

All five RJ45 ports support 10Mbps, 100Mbps, and 1000Mbps speeds with automatic negotiation. Ports one through four provide standard PoE, while the fifth carries network data without supplying PoE power. That fifth port is convenient for connecting a router, recorder, or upstream switch. Each port also supports Auto MDI/MDIX, which removes the usual concern about crossover cables. Actual transfer speeds depend on your cables, connected hardware, and network activity.

Four Standard PoE Ports

The V1 TL-SG1005P supports IEEE 802.3af Power over Ethernet on ports one through four. Each powered port can deliver up to 15.4 watts, subject to a shared total budget of 56 watts. Before installation, compare each device’s maximum consumption with both limits. Night-vision cameras may draw additional power when infrared illumination activates. Equipment requiring higher-power PoE+, passive PoE, or an incompatible voltage needs another suitable power source or switch.

Intelligent Power Management

Built-in intelligent power management helps prevent overload when the combined demand of connected devices exceeds the available 56W budget. The switch can stop supplying power to lower-priority ports to preserve more important powered connections. This is a protective feature rather than an invitation to overload the switch continuously. Plan power use around peak requirements, confirm device compatibility, and leave a reasonable margin for varying conditions.

Gigabit Switching Performance

The manufacturer specifies 10Gbps switching capacity and a 2K MAC address table for this hardware version. Automatic address learning helps the switch forward frames efficiently, while store-and-forward operation examines received Ethernet frames before sending them onward. IEEE 802.3x flow control supports more orderly transmission with compatible equipment. These capabilities suit everyday business networking and many small surveillance installations without requiring managed-switch configuration.

QoS and Multicast Optimization

Built-in 802.1p/DSCP Quality of Service helps prioritize latency-sensitive data, such as voice communication and video traffic. IGMP Snooping improves multicast handling so supported streaming traffic does not needlessly reach unrelated ports. These features operate within the switch’s unmanaged design; they do not provide a configurable VLAN dashboard, per-port monitoring, or advanced centralized management. For complex network segmentation, select an appropriate managed switch.

Simple Setup and Quiet Design

Installation is straightforward: connect the supplied power adapter, plug in suitable Ethernet cables, and confirm link status using the port indicators. No controller, application, or subscription is required. The compact metal enclosure provides durable protection, and fanless construction operates quietly around desks and reception counters. Desktop placement or compatible wall mounting allows flexible positioning. Keep the switch ventilated, dry, and away from excessive heat. For best results, use Cat5e or better cables for Gigabit links, identify which PoE devices are connected to each port, and test operation after installation and during maintenance. These simple checks help reduce troubleshooting time later.

Buy TP-Link TL-SG1005P in Pakistan

This switch is a practical choice for networks needing four standard PoE connections alongside a Gigabit uplink. It does not have built-in Wi-Fi and cannot provide PoE+ power beyond V1 limits. Newer TL-SG1005P hardware revisions have different power budgets and capabilities, so verify the version printed on the unit before purchasing. At Smartlinks Pakistan, confirm stock, included adapter, warranty terms, and your devices’ maximum power requirements before completing an order.
