Hikvision DS-K1T671MF Face Recognition & Fingerprint Terminal

Hikvision DS-K1T671MF Face Recognition Terminal

The Hikvision DS-K1T671MF is a professional biometric access control terminal designed for organizations that require fast, flexible and convenient identity authentication. It combines face recognition, fingerprint verification and M1 card authentication within one integrated device, giving businesses multiple options for managing authorized entry.

With its large touchscreen, dual-camera system and professional access-control interfaces, the DS-K1T671MF is suitable for offices, corporate facilities, educational institutions, commercial buildings, warehouses and other locations where controlled access is required.

Its combination of biometric authentication and network connectivity also makes it a practical option for businesses looking to modernize their existing access-control infrastructure.

Large 7-Inch Touchscreen

The Hikvision DS-K1T671MF Face Recognition Terminal features a large 7-inch LCD capacitive touchscreen.

The generous display area makes information easier to view while providing a convenient interface for user interaction and authentication. Compared with smaller access terminals, the 7-inch screen gives the unit a prominent and professional appearance at reception areas and controlled entrances.

Dual 2MP Camera System

The terminal is equipped with two 2MP camera lenses designed to support facial recognition.

The dual-camera arrangement captures the facial information required for biometric authentication and allows registered personnel to verify their identity without relying entirely on a physical access card.

This contactless authentication method can be particularly convenient in busy workplaces where employees enter and leave throughout the day.

Fast Face Recognition

Speed is an important consideration for access-control systems, especially at busy staff entrances.

The Hikvision DS-K1T671MF biometric terminal is designed to perform face recognition in less than 0.2 seconds per person under specified conditions.

It supports a facial recognition distance of approximately 0.3 to 3 metres, giving registered users a practical authentication range as they approach the terminal.

Fast recognition can help reduce queues and improve the overall entry experience during peak arrival and departure times.

Fingerprint Authentication

The DS-K1T671MF includes a built-in fingerprint recognition module, providing another biometric method for identity verification.

Fingerprint authentication can be used where organizations want an alternative to facial recognition or need multiple credential options for different users.

Combining fingerprint and face authentication in one terminal can also reduce the need to install separate biometric readers at the same entrance.

M1 Card Authentication

The Hikvision DS-K1T671MF includes support for M1 cards operating at 13.56 MHz.

Card-based authentication remains a practical solution for organizations that already issue access cards to employees, contractors or other authorized personnel.

By providing face, fingerprint and card authentication in one device, the DS-K1T671MF gives administrators greater flexibility when designing an access-control system.

QR Code Recognition

The terminal also supports QR code recognition, adding another useful authentication capability.

QR code support can be useful for compatible access-control workflows where digital credentials are preferred. This makes the device more flexible than terminals limited exclusively to biometric or physical card authentication.

Face Anti-Spoofing

The Hikvision DS-K1T671MF Face Access Terminal supports face anti-spoofing technology.

This functionality is designed to strengthen facial verification and improve the reliability of biometric authentication. For businesses using face recognition as a primary access method, anti-spoofing provides an important additional capability within the authentication process.

Gigabit Ethernet Connectivity

Reliable networking is essential for professional access-control systems.

The DS-K1T671MF features an RJ-45 network interface supporting 10/100/1000 Mbps self-adaptive Ethernet.

Gigabit-capable wired connectivity allows the terminal to communicate through compatible network infrastructure and provides a stable networking option for professional installations.

Professional Access Control Interfaces

The Hikvision DS-K1T671MF provides a wide selection of interfaces for integration with compatible access-control equipment.

It includes lock control, exit button input, door contact input and tamper protection. The terminal also provides RS-485 and Wiegand interfaces, allowing integration with compatible readers and other access-control equipment.

In addition, the device provides two alarm inputs and one alarm output, giving installers further flexibility when building a complete access-control solution.

USB Connectivity

USB connectivity is also available, adding flexibility for supported device management and related operations.

The official specification lists two USB interfaces, providing additional connectivity for compatible applications.

Audio with Noise Suppression

The DS-K1T671MF includes audio functionality with noise suppression and echo cancellation.

These audio-processing technologies are designed to improve sound clarity in supported applications, particularly in environments where background noise or acoustic echo could affect communication quality.

Designed for Demanding Environments

The terminal is specified to operate in temperatures ranging from approximately -30°C to 60°C, allowing it to function across a wide range of environmental conditions when correctly installed.

Its professional construction makes it suitable for commercial access applications where reliable operation is required throughout daily business activities.

Hikvision Platform Compatibility

The Hikvision DS-K1T671MF Face Recognition Terminal supports integration with compatible Hikvision platforms, including HikCentral Professional and Hik-ProConnect.

This helps organizations incorporate the terminal into a broader Hikvision access-control environment where compatible user and access-management functions can be administered more centrally.

Professional Biometric Access Solution

The Hikvision DS-K1T671MF Face Recognition & Fingerprint Terminal brings together multiple identity verification technologies within one professional access-control device.

Its 7-inch touchscreen, dual 2MP cameras, fingerprint recognition, M1 card support, QR code recognition, face anti-spoofing and Gigabit Ethernet provide the flexibility required for a variety of commercial access applications.

Combined with RS-485, Wiegand, alarm interfaces, door lock control and other professional connections, the DS-K1T671MF is a practical choice for businesses looking to build a modern biometric access-control system.
