Hikvision DS-K1T342EFWX Face Recognition & Fingerprint Terminal

Hikvision DS-K1T342EFWX Face Recognition Terminal

The Hikvision DS-K1T342EFWX is a modern biometric face recognition terminal designed to provide fast and convenient identity verification for access control and attendance applications. Combining face recognition, fingerprint authentication and EM card verification in one compact unit, it provides businesses with several ways to manage employees and authorized users.

Designed for professional access environments, the DS-K1T342EFWX offers useful user capacity, quick face recognition and flexible networking. It is suitable for offices, corporate environments, educational facilities, commercial locations and other workplaces that need an organized biometric access solution.

4.3-Inch Capacitive Touchscreen

The Hikvision DS-K1T342EFWX Face Recognition Terminal features a 4.3-inch LCD capacitive touchscreen. The responsive display provides a convenient interface for authentication, configuration and everyday interaction.

Its touchscreen design helps users interact naturally with the device while maintaining a clean and professional appearance suitable for modern business entrances.

Dual 2MP Camera Lenses

The terminal is equipped with two 2MP camera lenses for facial authentication. The dual-lens configuration works with the terminal’s facial recognition technology to provide quick identity verification.

This camera system makes contactless authentication convenient for registered users, reducing dependence on physical credentials for everyday access.

Fast Face Recognition

Speed is an important requirement for busy entrances. The DS-K1T342EFWX offers facial recognition in less than 0.2 seconds per user, with a specified recognition distance from approximately 0.3 to 1.5 metres.

Its specified face recognition accuracy is at least 99% under Hikvision’s test conditions, helping provide reliable identification while maintaining a smooth entry process.

1,500 Face Capacity

The Hikvision DS-K1T342EFWX biometric terminal can store up to 1,500 faces, providing sufficient facial credential capacity for many small and medium-sized businesses.

This makes it suitable for organizations that want to use facial recognition as a convenient primary authentication method for employees and other authorized users.

3,000 Fingerprints and 3,000 Cards

In addition to facial recognition, the terminal supports up to 3,000 fingerprints and 3,000 cards. The built-in card reading module supports 125 kHz EM cards.

Having face, fingerprint and card authentication in one device gives businesses greater flexibility. Different users can be assigned authentication methods according to workplace policies and operational requirements.

150,000 Event Capacity

The Hikvision DS-K1T342EFWX can store up to 150,000 events, providing substantial capacity for everyday authentication and access activity.

Large event storage is useful for organizations that need to maintain access or attendance records over extended periods while managing many daily user transactions.

Wi-Fi and Gigabit Ethernet

Flexible network connectivity makes the terminal easier to integrate into different installations. It supports 2.4GHz Wi-Fi with IEEE 802.11b/g/n, allowing wireless communication through a compatible network.

For wired installations, the terminal includes an RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface. Businesses can therefore choose wired or wireless connectivity according to their network infrastructure.

Face Anti-Spoofing and Mask Recognition

The DS-K1T342EFWX includes face anti-spoofing functionality, designed to strengthen facial authentication and help provide more dependable access verification.

The terminal also supports mask recognition, giving organizations additional functionality for environments where detecting mask usage may be useful.

Two-Way Audio

The Hikvision DS-K1T342EFWX supports two-way audio with compatible client software, indoor stations and main stations.

Its audio system includes a built-in omnidirectional microphone and loudspeaker, while noise suppression and echo cancellation help provide clearer communication.

This makes the terminal useful in access environments where communication with visitors or personnel may also be required.

Professional Access Control Connectivity

The terminal provides multiple interfaces for integration with compatible access control equipment. Connections include lock control, exit button, door contact input, tamper, RS-485, Wiegand and USB.

These interfaces allow the DS-K1T342EFWX to operate as part of a more complete door access system instead of functioning only as a standalone biometric reader.

Attendance and Web Management

The terminal supports an attendance-only function, making it suitable for employee attendance applications as well as controlled entry.

Configuration through a web client provides administrators with a convenient way to manage compatible settings. Support for ISAPI and ISUP 5.0 also provides integration possibilities within compatible Hikvision environments.

Smart Biometric Solution for Businesses

The Hikvision DS-K1T342EFWX Face Recognition & Fingerprint Terminal brings together fast facial recognition, fingerprint verification, EM card authentication and professional access-control connectivity.

With capacity for 1,500 faces, 3,000 fingerprints, 3,000 cards and 150,000 events, the device is well equipped for everyday business access and attendance applications.

Its 4.3-inch touchscreen, dual 2MP lenses, Wi-Fi, Gigabit Ethernet, two-way audio, face anti-spoofing and multiple access interfaces provide organizations with a flexible biometric platform for modern entry management.
