Hikvision DS-K1T320MFWX Face Recognition & Fingerprint Access Terminal

Hikvision DS-K1T320MFWX Face Recognition Terminal

The Hikvision DS-K1T320MFWX is a versatile face recognition and access control terminal designed to provide convenient identity authentication for modern workplaces and controlled entry points. Combining face recognition, fingerprint verification, M1 card authentication and PIN access in one compact unit, it gives businesses multiple ways to manage authorized users.

Suitable for offices, commercial buildings, educational environments, shops and other professional locations, the DS-K1T320MFWX combines a compact design with fast authentication and useful networking capabilities.

Fast Face Recognition

A major feature of the Hikvision DS-K1T320MFWX Face Recognition Terminal is its fast facial authentication technology. The terminal supports face recognition in less than 0.2 seconds per user, helping provide a quick entry experience during busy working hours.

The device also supports face anti-spoofing, adding another layer of protection to the facial authentication process.

2MP Camera and 2.4-Inch Display

The DS-K1T320MFWX is equipped with a 2MP lens for facial recognition. Its built-in 2.4-inch LCD screen provides a convenient interface for authentication and device operation.

The compact screen and camera arrangement make the terminal suitable for locations where businesses need capable access control functionality without installing a large terminal.

Multiple Authentication Methods

Flexibility is an important advantage of the Hikvision DS-K1T320MFWX. Instead of depending on only one authentication method, the terminal supports multiple options, including face, fingerprint, M1 card and PIN authentication.

This allows businesses to choose suitable authentication methods according to their access control requirements. Different verification options can also make the system more convenient for employees and authorized users.

Large User and Event Capacity

Despite its compact dimensions, the Hikvision DS-K1T320MFWX provides useful storage capacity for everyday commercial applications.

The terminal supports up to 500 faces, 1,000 fingerprints and 1,000 cards. It can also store up to 100,000 events, providing sufficient capacity for many small and medium-sized organizations.

This makes it suitable for businesses looking for a scalable biometric access solution without unnecessary complexity.

Wi-Fi and Wired Network Connectivity

The DS-K1T320MFWX biometric terminal provides both wired and wireless networking options. It supports 2.4GHz Wi-Fi with IEEE 802.11b/g/n standards for wireless connectivity.

For wired installations, the device includes an RJ-45 10/100 Mbps self-adaptive Ethernet interface. Having both options provides greater flexibility when planning installation at different locations.

Built-In Access Controller

The terminal features a built-in access controller and provides dedicated interfaces for access control applications. These include lock control, exit button and door contact input connections.

A tamper interface is also available, while a USB port provides additional connectivity. These features allow the terminal to serve as more than a basic attendance device and make it useful as part of a controlled door-entry system.

Easy Web-Based Configuration

The Hikvision DS-K1T320MFWX supports configuration through a web client, giving administrators a convenient method for managing compatible device settings.

It also supports ISAPI and ISUP 5.0 protocols, offering integration possibilities for compatible security and management environments.

Reliable Choice for Modern Businesses

With fast facial authentication, fingerprint verification, M1 card support, PIN authentication and flexible network connectivity, the Hikvision DS-K1T320MFWX provides a practical combination of access control and identity verification features.

Its 500-face capacity, 1,000 fingerprint capacity, 1,000-card capacity and 100,000-event storage make it particularly useful for offices and organizations requiring reliable everyday access management.

For businesses looking for a compact Hikvision biometric terminal with several authentication methods, wired networking and Wi-Fi connectivity, the DS-K1T320MFWX offers a capable solution for modern access control environments.
