- Camera
- Image Sensor 1/2.8″ Progressive Scan CMOS
- Max. Resolution 2560 × 1440
- Min. Illumination Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR
- Shutter Time 1/3 s to 1/100,000 s
- Day & Night IR cut filter
- Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
- Lens
- Lens Type Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV
4 mm, horizontal FOV 82°, vertical FOV 45°, diagonal FOV 98°
- Lens Mount M12
- Iris Type Fixed
- Aperture F2.2
- Depth of Field
4 mm: 1.1 m to ∞
- DORI
- DORI
4 mm, D: 67 m, O: 26 m, R: 13 m, I: 6 m
- Illuminator
- Supplement Light Type IR,White Light
- Supplement Light Range Up to 20 m
- Smart Supplement Light Yes
- IR Wavelength 850 nm
- Video
- Main Stream
50 Hz:
20 fps (2560 × 1440),
25 fps (1920 × 1080, 1280 × 720)
60 Hz:
20 fps (2560 × 1440),
24 fps (1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 25 fps (1280 × 720，640 × 480, 640 × 360)
60 Hz: 24 fps (1280 × 720，640 × 480, 640 × 360)
- Video Compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate 32 Kbps to 8 Mbps
- H.264 Type Baseline Profile,Main Profile,High Profile
- H.265 Type Main Profile
- Bit Rate Control CBR,VBR
- Region of Interest (ROI)1 fixed region for main stream
- Audio
- Audio Type Mono sound
- Environment Noise Filtering Yes
- Audio Sampling Rate 8 kHz/16 kHz
- Audio Compression G.711ulaw/AAC-LC
- Audio Bit Rate 64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
- Network
- Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS, SNMP, DDNS
- API ONVIF (Profile S, Profile T, Profile G (only -F model supports Profile G)),ISAPI,SDK
- Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- Simultaneous Live View Up to 6 channels
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Client iVMS-4200,Hik-Connect
- Web Browser
Local service: Chrome 80+, Firefox 80+, Edge 89+, IE 11
- Image
- Wide Dynamic Range (WDR)Digital WDR
- SNR≥ 52 dB
- Day/Night Switch Day,Night,Auto,Schedule
- Image Enhancement BLC,HLC,3D DNR
- Image Settings Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
- Privacy Mask 1 programmable polygon privacy mask
- Interface
- Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
- Built-in Microphone Yes,1 built-in microphone
- Event
- Basic Event Motion detection (support alarm triggering by specified target type (human)), exception
- Linkage Upload to memory card (-F model supports), send email, notify surveillance center, trigger recording (-F model supports), trigger capture
- General
- Power
12 VDC ± 25%, 0.42 A, max. 5 W, Ø5.5 mm coaxial power plug, reverse polarity protection,
PoE: IEEE 802.3af, Class 0, max. 6.5 W
- Material Metal & Plastic
- Dimension Ø 110 mm × 89.2 mm (Ø4.3″ × 3.5″)
- Package Dimension 150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
- Approx. 345 g (0.7 lb.)
- With Package Weight Approx. 588 g (1.2 lb.)
- Storage Conditions -30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions -30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
- Language English, Ukrainian
- General Function Heartbeat,anti-banding,mirror,password protection,password reset via email
- Protection IP67: IEC 60529-2013
