Hikvision DS-K1T642MFW Face Recognition & Fingerprint Terminal

Hikvision DS-K1T642MFW Face Recognition Terminal

The Hikvision DS-K1T642MFW is a professional biometric face recognition terminal designed for businesses and organizations that require fast, flexible and convenient identity authentication. Combining face recognition, fingerprint verification and M1 card authentication in one compact unit, it provides multiple methods for managing authorized entry and employee attendance.

With high credential capacity, fast facial authentication and flexible network connectivity, the DS-K1T642MFW is suitable for offices, corporate buildings, educational institutions, warehouses, commercial facilities and other controlled environments.

Its modern touchscreen design and multiple access-control interfaces also make it a practical choice for professional security installations.

4.3-Inch IPS Capacitive Touchscreen

The Hikvision DS-K1T642MFW Face Recognition Terminal features a 4.3-inch IPS capacitive touchscreen. The display provides a convenient interface for user authentication and device operation.

Its touchscreen design allows users to interact naturally with the terminal while maintaining a compact and professional appearance at reception areas, staff entrances and other controlled access points.

Dual 2MP Camera Lenses

The DS-K1T642MFW is equipped with dual 2MP camera lenses for facial authentication. This camera arrangement captures facial information for fast biometric verification.

Face recognition provides a convenient contactless authentication option, allowing registered users to verify their identity without depending entirely on physical cards.

Fast Face Recognition

Quick authentication is essential at busy entrances. The Hikvision DS-K1T642MFW biometric terminal provides a specified facial recognition duration of less than 0.2 seconds per user.

It supports a recognition distance of approximately 0.3 to 3 metres, providing users with convenient authentication as they approach the terminal.

Hikvision specifies a face recognition accuracy rate of 99% or higher under its defined test conditions, providing dependable performance for compatible access-control applications.

6,000 Face Capacity

The DS-K1T642MFW supports up to 6,000 registered faces, providing substantial biometric capacity for organizations with large numbers of employees or authorized users.

This makes the terminal suitable not only for smaller offices but also for larger commercial facilities where thousands of users may need to be enrolled.

5,000 Fingerprint Capacity

In addition to facial authentication, the Hikvision DS-K1T642MFW supports up to 5,000 fingerprints.

Fingerprint verification provides another biometric authentication option and can be useful when organizations want to provide employees with more than one method of identity verification.

Combining facial and fingerprint recognition in one terminal also reduces the need for separate biometric devices.

10,000 M1 Card Capacity

The terminal supports up to 10,000 M1 cards, providing excellent capacity for card-based access applications.

Its M1 card reader operates at 13.56 MHz, allowing compatible cards to be assigned to authorized personnel.

Card authentication can be used alongside biometric verification, giving organizations flexibility when designing access policies for different employees or departments.

QR Code Recognition

The DS-K1T642MFW Face Access Terminal also supports QR code recognition.

QR authentication provides another convenient option for compatible access scenarios and can be useful where organizations want to incorporate digital credentials into their access-control environment.

This makes the terminal more versatile than systems limited only to face, fingerprint or physical card authentication.

150,000 Event Capacity

The device can store up to 150,000 events, providing substantial capacity for access and attendance activity.

This is particularly useful in workplaces where hundreds or thousands of authentication events may occur throughout the working day.

Face Anti-Spoofing Technology

The Hikvision DS-K1T642MFW supports face anti-spoofing functionality to strengthen facial authentication.

This capability is designed to improve the reliability of face-based verification and makes the terminal more suitable for professional environments where controlled entry is important.

Mask Detection and Wearing Alerts

The terminal includes intelligent face mask detection functionality.

Depending on the configured mode, the system can provide a voice reminder when a person is not wearing a mask. Hikvision also provides configurable mask-related authentication behavior, allowing the feature to be adapted to different workplace requirements.

Wi-Fi and Gigabit Ethernet

Flexible networking makes the DS-K1T642MFW easier to integrate into different environments.

It supports 2.4GHz Wi-Fi using IEEE 802.11b/g/n, providing wireless connectivity through a compatible network.

For wired installations, the terminal includes an RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface, providing Gigabit-capable network connectivity.

Professional Access Control Integration

The Hikvision DS-K1T642MFW Face Recognition Terminal includes multiple interfaces for integration with professional door-access equipment.

It provides connections for lock control, exit button, door contact and tamper protection. It also includes RS-485, Wiegand and USB interfaces, providing flexibility for compatible access-control installations.

These interfaces allow the terminal to function as part of a complete access-management solution rather than simply as a standalone biometric reader.

Two-Way Audio

The terminal supports two-way audio with compatible indoor stations and main stations.

Its audio system includes noise suppression and echo cancellation, helping provide clearer communication in supported access-control configurations.

This functionality can be useful at entrances where communication between users and reception or security personnel is required.

Attendance Management

The DS-K1T642MFW supports multiple attendance states, including check in, check out, break in, break out, overtime in and overtime out.

This makes the terminal useful not only for door access but also for organizations that need a more structured employee attendance workflow.

Web-Based Configuration

Configuration through a web client provides administrators with a convenient method for managing compatible device settings.

The terminal also supports ISAPI and ISUP 5.0, allowing it to integrate into compatible Hikvision management environments.

Professional Biometric Access Solution

The Hikvision DS-K1T642MFW Face Recognition & Fingerprint Terminal combines high user capacity, multiple authentication methods and professional access-control connectivity in one compact device.

With 6,000 faces, 5,000 fingerprints, 10,000 M1 cards, 150,000 event capacity, QR recognition, Wi-Fi and Gigabit Ethernet, it provides the scalability required for demanding business environments.

Its fast face recognition, 4.3-inch touchscreen, dual 2MP cameras, face anti-spoofing, mask detection, two-way audio and professional interfaces make the DS-K1T642MFW a powerful option for modern access control and employee attendance applications.
