Hikvision DS-K1T344MBWX-QRE1 Face Recognition Terminal

The Hikvision DS-K1T344MBWX-QRE1 is a modern Value Series face access terminal designed for businesses that require fast, flexible and convenient identity authentication. Combining facial recognition, M1 card reading, PIN verification and QR code authentication in one compact unit, it provides multiple ways to manage authorized entry.

Designed for offices, corporate buildings, educational facilities, commercial locations and other controlled environments, the DS-K1T344MBWX-QRE1 offers useful capacity along with wired and wireless connectivity. Its IP65-rated construction also provides additional flexibility when choosing an appropriate installation location.

4.5-Inch LCD Touchscreen

The Hikvision DS-K1T344MBWX-QRE1 Face Access Terminal features a 4.5-inch LCD touchscreen with a resolution of 480 × 854 pixels.

The touchscreen provides a clear and convenient interface for everyday operation and authentication. Its modern design allows the terminal to fit neatly at office entrances, reception areas and other controlled access points.

Dual-Lens 2MP Camera System

Facial authentication is supported by a dual-lens camera arrangement with 2MP imaging. The camera system captures the facial information required for biometric identification while providing a convenient contactless method of authentication.

Registered employees and authorized users can authenticate without depending exclusively on a physical card.

Fast Face Recognition

Quick authentication is particularly important at busy entrances. The DS-K1T344MBWX-QRE1 offers a specified face recognition time of less than 0.2 seconds per user.

The terminal supports a facial recognition distance of approximately 0.3 to 1.5 metres, allowing users to authenticate conveniently as they approach the device.

Hikvision specifies a face recognition accuracy rate above 99% under its defined test conditions, providing a capable platform for professional access applications.

3,000 Face and User Capacity

The Hikvision DS-K1T344MBWX-QRE1 supports up to 3,000 users and 3,000 registered faces.

This capacity makes the terminal suitable for many small and medium-sized businesses as well as larger facilities that require centralized management of a substantial number of authorized users.

M1 Card Authentication

The terminal incorporates an M1 card reading module operating at 13.56 MHz and supports up to 3,000 cards.

Card authentication provides a familiar access method for organizations that already issue staff access cards. It can be used alongside the terminal’s facial, PIN and QR authentication capabilities.

Face, Card, PIN and QR Authentication

One of the strongest features of the DS-K1T344MBWX-QRE1 biometric access terminal is its support for several authentication methods.

Users can authenticate through face recognition, M1 card, PIN or QR code. QR codes can be scanned using the supported QR module or camera, giving organizations another convenient option for compatible access scenarios.

This flexibility allows businesses to configure access procedures according to different user and operational requirements.

150,000 Event Capacity

The terminal can store up to 150,000 events, providing substantial capacity for everyday access activity.

Large event storage is particularly useful for commercial environments where employees and authorized users may authenticate many times throughout the working day.

Wi-Fi, Bluetooth and Ethernet

Flexible network connectivity makes installation easier. The Hikvision DS-K1T344MBWX-QRE1 supports Wi-Fi and Bluetooth, providing useful wireless capabilities for compatible configurations.

For wired installations, the device provides 10/100 Mbps self-adaptive Ethernet. Businesses can therefore choose an appropriate connectivity method according to their existing network infrastructure.

Standard PoE Support

The DS-K1T344MBWX-QRE1 supports both 12V DC power and standard PoE. PoE can simplify installation by allowing compatible network infrastructure to carry power and data.

The terminal can also support powering a compatible door lock when installed according to Hikvision’s specified PoE configuration, helping simplify certain access-control installations.

Professional Access Control Interfaces

The terminal provides multiple interfaces for integration with professional access-control equipment.

It includes RS-485, Wiegand input, lock control, exit button, door contact input, tamper protection and USB connectivity. It also provides two alarm inputs and one alarm output.

These interfaces allow the terminal to function as an important part of a complete door-access system rather than simply operating as a standalone face reader.

Face Anti-Spoofing

The Hikvision DS-K1T344MBWX-QRE1 supports face anti-spoofing functionality, designed to strengthen facial authentication and help provide more dependable identity verification.

This makes facial recognition more appropriate for professional environments where controlled access and reliable user authentication are important.

Two-Way Audio

Two-way audio is another useful feature of the terminal. It can support audio communication with compatible client software, indoor stations and main stations.

This functionality can be useful at entrances where visitors or employees may need to communicate with reception or security personnel.

IP65 Protection

The terminal carries an IP65 protection rating, providing protection against dust and water ingress according to the conditions defined by the rating.

Its specified operating temperature range extends from -30°C to 60°C, giving installers flexibility across a variety of environmental conditions when Hikvision’s installation guidelines are followed.

Convenient Web Configuration

The DS-K1T344MBWX-QRE1 supports configuration through both mobile web and PC web interfaces.

Web-based configuration can make administration more convenient by allowing compatible settings to be managed without performing every task directly on the terminal.

Smart Access Control for Modern Businesses

The Hikvision DS-K1T344MBWX-QRE1 Face Recognition Access Terminal combines modern biometric identification with card, PIN and QR authentication in one professional device.

With 3,000-face capacity, 3,000-card capacity, 150,000 event storage, fast facial recognition, Wi-Fi, Bluetooth, Ethernet, PoE, two-way audio and IP65 protection, it provides a flexible platform for modern access control.

For offices, commercial buildings, educational facilities and other professional environments, the DS-K1T344MBWX-QRE1 provides a capable solution for managing authorized entry while offering users several convenient authentication methods.
